1X 54/55w T5 HO/PLL III 220-240v IDC - Philips - 913713028266 - HF-P 154/155 TL5 HO/PLL II 220-240v Downloads Spec SheetSize:203.6 kB Specifications Operating and Electrical Input Voltage 220 to 240 V Line Frequency 50 to 60 Hz Inrush Current Width 0.25 ms Input Frequency 50 to 60 Hz Inrush Current Peak (Max) 24 A Approval and Application Ingress protection code IP20  [Finger-protected] Environmental Standard ISO 14001 Energy Efficiency Index A2 BAT Approval Marks CE marking ENEC certificate VDE-EMV certificate Safety Standard IEC 61347-2-3 Product Data Numerator - Quantity Per Pack 1 Order code 913713028266 Order product name HF-P 154/155 TL5 HO/PLL III 220-240V IDC Full product code 872790086348200 Net weight 0.252 kg Full product name HF-P 154/155 TL5 HO/PLL III 220-240V IDC EAN/UPC - Case 8727900863482 Numerator - Packs per outer box 12 Material number (12NC) 913713028266 Mechanical and Housing Housing L360x30x22 General Information Number of Lamps 1 piece/unit Number of Products on MCB (16A Type B) (Nom) 28 Brand Philips Wiring Connector Type Input Terminals WAGO 251 universal connector  [Suitable for both automatic wiring (ALF and ADS) and manual wiring] Connector Type Output Terminals WAGO 251 universal connector  [Suitable for both automatic wiring (ALF and ADS) and manual wiring] Temperature T-Case Maximum (Max) 80 °C Ambient temperature range -25 °C to 60 °C T-Case Lifetime (Nom) 80 °C Installation diagrams HF-P 154/155 TL5 HO/PLL III 220-240V IDC Wiring Diagram - HF-P 154/155 TL5 HO/PLL III 220-240V IDC

Read more less

obsolete please order the Osram alternative, Link below   Alternative  1x55w TL5C Performer Ballast HFP155TL5C

Read more less

Philips Electronic HF performer II TL-D ballast to run 1x58w or 1 x70W T8 Tubes - HFP158TLDEII Specifications General information Application Code III Type Version IDC Lamp Type TL-D/PL-L Number of Lamps 1 piece/unit Number of Products on MCB (16A Type B) (Nom) 28 Automatic Restart Yes Operating and electrical Input Voltage 220 to 240 V Input Frequency 50 to 60 Hz Operating Frequency (Nom) 45 kHz Ignition Method Programmed Start Crestfactor (Max) 1.7 Power Factor 100% Load (Nom) 0.99 Ignition Time (Max) 0.9 s Mains Voltage Performance (AC) -8%-+6% Mains Voltage Safety (AC) -10%-+10% Earth Leakage Current (Nom) 0.5 mA Inrush Current Width 0.25 ms Constant Wattage Deviation -2%/+2% Ballast Factor (Nom) 0.95 Power Factor (Nom) 0.99 Power Losses (Nom) 4.3-4.4 W Inrush Current Peak (Max) 18 A Efficiency at full load [%] 93.3 % Wiring Connector Type Input Terminals WAGO 251 universal connector  [ Suitable for both automatic wiring (ALF and ADS) and manual wiring] Cable Capacity Output Wires Mutual (Nom) 200 pF Connector Type Output Terminals WAGO 251 universal connector  [ Suitable for both automatic wiring (ALF and ADS) and manual wiring] Cable Length Hot Wiring 0.75 m Wire Striplength 8.0-9.0 mm Dual Fixture Master/Slave Not applicable  [ Master/Slave oper. not applicable] Input Terminal Cross Section 0.50-1.00 mm² Output Terminal Cross Section 0.50-1.00 mm² Cable Capacity Output Wires to Earth (Nom) 200 pF System characteristics Rated Ballast-Lamp Power 58 W Rated Lamp Power on TL-D 58 W System Power on TL-D 56.3W@58W; 63.8W@70 W Lamp Power on TL-D 51.9W@58W; 59.6W@70 W Power Loss on TL-D 4.4W@58W; 4.3W@70 W System Power on PL-L 55.8W@55 W Lamp Power on PL-L 51.5W@55 W Power Loss on PL-L 4.3W@55 W Temperature T-Ambient (Max) 60 °C T-Ambient (Min) -25 °C T-Storage (Max) 50 °C T-Storage (Min) -40 °C T-Case Lifetime (Nom) 80 °C T-Case Maximum (Max) 80 °C T-Ignition (Max) 60 °C T-Ignition (Min) -25 °C Mechanical and housing Housing L 280x30x28 Emergency operation Nominal Light Output After 60 Seconds 100% of EBLF Battery Voltage Lamp Ignition 186-275 V Normal Operating Voltage (DC) 220-240 V Battery Voltage Lamp Operation 186-275 Battery Voltage Guaranteed Operation 176-275 V Battery Voltage Guaranteed Ignition 186-275 V Emergency Ballast Lumen Factor (EBLF) (Nom) 100 % Nominal Light Output After 5 Seconds 50% of EBLF Approval and application Energy Efficiency Index A2 BAT IP Classification IP 20  [ Ingress Protection 20] EMI 9 kHz ... 30 MHz EN55015 EMI 30 MHz ... 1000 MHz EN55022 level B Safety Standard IEC 61347-2-3 Performance Standard IEC 60929 Quality Standard ISO 9000:2000 Environmental Standard ISO 14001 Harmonic Current Emission Standard IEC 61000-3-2 EMC Immunity Standard IEC 61547 Vibration Standard IEC68-2-6 F c Bumps Standard IEC 68-2-29 Eb Humidity Standard EN 61347-2-3 clause 11 Approval Marks CE marking ENEC certificate VDE-EMV certificate Temperature Marking Yes Emergency Standard IEC 60598-2-22 Hum And Noise Level < 30 dB(A) Product data Full product code 872790091170100 Order product name HF-P 158 TL-D III 220-240V 50/60Hz IDC EAN/UPC - Product 8711500999702 Order code 913713031866 Numerator - Quantity Per Pack 1 Numerator - Packs per outer box 12 Material Nr. (12NC) 913713031866 Net Weight (Piece) 0.205 kg Installation diagrams HF-P 158 TL-D III 220-240V 50/60Hz IDC HF-P 158 TL-D III 220-240 V 50/60 Hz IDC

Read more less

Philips Electronic 14/35w TL5 Ballast This is Philips second generation slim,lightweight HF Electroniic Ballasts Electroniic Ballasts For T8 25mm TL-D Lamps, using philips EII technology Suitable for single T8 5'/1500mm 58 Watt Lamps. Dimensions - Height 28mm , Width 278mm , Depth 28mm

Read more less

Philips Electronic 14/35w TL5 Ballast This is Philips second generation slim,lightweight HF Electroniic Ballasts Electroniic Ballasts For T8 25mm TL-D Lamps, using philips EII technology Suitable for single T8 5'/1500mm 58 Watt Lamps. Dimensions - Height 28mm , Width 278mm , Depth 28mm

Read more less

Philips Electronic HF performer PLL ballast to run 2x 40w PLL - HFP240PLL

Read more less

Philips Electronic HF performer II TL-D ballast to run 3/4x 18w T8 Tubes - HFP3418TLDEII

Read more less

  This item no longer available please consider the below item as a viable alternative   Alternative    1x39w TL5 1-10v Analogue Dimming Ballast - HFR139TL5E11 - 91468230

Read more less

Philips Electronic HF Regulator Ballast using 1-10v protocol to run 1x40w PLL lamps- HFR140PLLEII

Read more less

150w CDM Electronic Ballast - Philips - Primavision - HID-PV C 150/S - 913700614066

Read more less

HID-PV XT 45 CPO Q 208-277V - PVXT45CPOQ - 871829166896100 Input Voltage 208-240-277 V Line Frequency 50 to 60 Hz Input Frequency 50 to 60 Hz Earth Leakage Current (Max) 0.7 mA Inrush Current Width 0.24 ms Input Current (Nom) 0.26 A Inrush Current Peak (Max) 28 A Number of Products on MCB (16A Type B) (Nom) 5

Read more less

100-600W SON-E/T 35-150W CDM IGNITOR - Philips SN58 - SN 58
