142020 - PROFESSIONALE SQUARE DALI 38 NFC

Description

TCI DALI Square NFC programmable driver

Features


•Driver for built-in use.
•It can be used for lighting equipment in protection class I and II.
•Active Power Factor Corrector.
•Current regulation ±5 % including temperature variations.
•Input and output terminal blocks on opposite sides (wire cross-section up to 1,5 mm2 / AWG15).
•Driver can be secured with slot for screws.
•Protections:
- against overheating and short circuits;
- against mains voltage spikes;
- against overloads

Operation Mode


•WIRELESS PROGRAMMING through NFC antenna.
•Programmable features:
- output current setting, step 1mA;
- PUSH-SWITCH (enable/disable);
- Password (lock/unlock programming).
•Compatible with standard DALI interfaces.
•Features DALI dimming (0/1 - 100 %, minimum output current 7 mA):
- memory function for sets or light groups;
- recall of stored functions.
•Dimming method is AMPLITUDE.
•Light regulation 0/1 - 100 % by means of PUSH SWITCH function (mains voltage):
- a short push to turn on and off;
- a longer push to increase or decrease light intensity;
- regulation automatically stops at minimum and maximum values;
- for another on, regulation or off command, release the push button and give the desired command again;
- dimming level memory at mains restore

142020 - PROFESSIONALE SQUARE DALI 38 NFC

Product form

SKU: 142020
Barcode: 142020

Stock Level: Ordered in - Delivery 2-3 Days

Trade price available - contact us

£55.00 Excl. VAT

(inc. 20% VAT): £66.00

    • Contact us to confirm availability
      Downloads

    TCI DALI Square NFC programmable driver Features •Driver for built-in use.•It can be used for lighting equipment in protection class... Read more

    Description

    TCI DALI Square NFC programmable driver

    Features


    •Driver for built-in use.
    •It can be used for lighting equipment in protection class I and II.
    •Active Power Factor Corrector.
    •Current regulation ±5 % including temperature variations.
    •Input and output terminal blocks on opposite sides (wire cross-section up to 1,5 mm2 / AWG15).
    •Driver can be secured with slot for screws.
    •Protections:
    - against overheating and short circuits;
    - against mains voltage spikes;
    - against overloads

    Operation Mode


    •WIRELESS PROGRAMMING through NFC antenna.
    •Programmable features:
    - output current setting, step 1mA;
    - PUSH-SWITCH (enable/disable);
    - Password (lock/unlock programming).
    •Compatible with standard DALI interfaces.
    •Features DALI dimming (0/1 - 100 %, minimum output current 7 mA):
    - memory function for sets or light groups;
    - recall of stored functions.
    •Dimming method is AMPLITUDE.
    •Light regulation 0/1 - 100 % by means of PUSH SWITCH function (mains voltage):
    - a short push to turn on and off;
    - a longer push to increase or decrease light intensity;
    - regulation automatically stops at minimum and maximum values;
    - for another on, regulation or off command, release the push button and give the desired command again;
    - dimming level memory at mains restore
