Product family features
Line frequency: 0 Hz | 50 Hz | 60 Hz
Versatile DALI window driver up to 75 W due to flexible output characteristic
Supply voltage: 220…240 V
Usable as DT6 (2-channel) or DT8 (Tunable White) driver*
Available with output current range: up to 700 mA
Constant Lumen Output (CLO)
Integrated customizable thermal management (Driver Guard)
Non-isolated drivers
Product family benefits
Control of standard white or Tunable White light acc. DALI device type 8 (DT8)*
TouchDIM Tunable White integrated for use without additional LMS
Fully programmable via T4T software (NFC, DALI Interface)
Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
High-quality dimming of 1…100 % (amplitude and/or PWM selectable by software)
High quality of light thanks to <1% output ripple current
Very high efficiency
Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Versatile scope of application due to DALI Technology:
Easy to use in corridors and restrooms because of three-level Corridor function
Touch DIM application: easy to control via pushbutton or sensor
Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
Feedback of power consumption and operating hours (Fit for SMART GRID)
Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
Luminaire information for easy maintenance
Areas of application
For Tunable White as well as for 2-channel use (e.g. direct/indirect lighting)
Linear lighting for office, education, industry, storage areas and retail
Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
Suitable for installation in emergency lighting systems according to EN 60598-2-22
Suitable for luminaires of protection class I
Perfect system match with PrevaLED Linear Tunable White
Ecodesign regulation information:
Intended for use with LED modules.
The forward voltage of the LED light source shall be within the defined operating window of the control gear in all operating conditions including dimming if applicable.
Separate control gear and light sources must be disposed of at certified disposal companies in accordance with Directive 2012/19/EU (WEEE) in the EU and with Waste Electrical and Electronic Equipment (WEEE) Regulations 2013 in the UK. For this purpose, collection points for recycling centres and take-back systems (CRSO) are available from retailers or private disposal companies, which accept separate control gear and light sources free of charge. In this way, raw materials are conserved and materials are recycled.
