APC-25-350 - Mean Well LED Driver APC-25-350 25W 350mA

Description

Constant CurrentFully isolated plastic caseProtections: Short circuit/ Overload/ Over voltageOther features: Universal AC input / Full RangeSmall and compact sizeWithstand 300VAC surge input for 5 secondsIsolation class II, no FGCooling by free air convectionPass LPS100% full load burn-in testLow cost, High reliability2 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 25 Output Current 350mA Dimmable (Type) No Output Voltage Range (V) 25~70 Dimensions 84x 57x 29.5 EMC Standards EN55022, EN61000-3-2 Class A, EN610003-3, EN55024, EN61000-4-2, 3, 4, 5, 6, 8, 11; light industry level (surge 2KV), criteria A Input Voltage 90~264VAC, 127VDC~370VDC Safety Standards Design refer to EN60950-1, UL8750 Output Voltage Options Single Working Temperature -30°C~+70°C (Refer to "Derating Curve") PDF Datasheet APC-25-spec.pdf

APC-25-350 - Mean Well LED Driver APC-25-350 25W 350mA

Product form

SKU: APC-25-350

Stock Level: Ordered in - Delivery 2-3 Days

Trade price available - contact us

£17.07 Excl. VAT

(inc. 20% VAT): £20.48

    • Contact us to confirm availability
      Downloads

    Constant CurrentFully isolated plastic caseProtections: Short circuit/ Overload/ Over voltageOther features: Universal AC input / Full RangeSmall and compact sizeWithstand... Read more

    Description

    Constant CurrentFully isolated plastic caseProtections: Short circuit/ Overload/ Over voltageOther features: Universal AC input / Full RangeSmall and compact sizeWithstand 300VAC surge input for 5 secondsIsolation class II, no FGCooling by free air convectionPass LPS100% full load burn-in testLow cost, High reliability2 years warranty
    More Information Manufacturer Mean Well Output Wattage (W) 25 Output Current 350mA Dimmable (Type) No Output Voltage Range (V) 25~70 Dimensions 84x 57x 29.5 EMC Standards EN55022, EN61000-3-2 Class A, EN610003-3, EN55024, EN61000-4-2, 3, 4, 5, 6, 8, 11; light industry level (surge 2KV), criteria A Input Voltage 90~264VAC, 127VDC~370VDC Safety Standards Design refer to EN60950-1, UL8750 Output Voltage Options Single Working Temperature -30°C~+70°C (Refer to "Derating Curve") PDF Datasheet APC-25-spec.pdf
