Driver LC 100W 250–700mA flexC lp EXC

Description

Driver LC 100W 250–700mA flexC lp EXC

excite series non-SELV

Product description

  • Constant current LED driver for luminaire installation
  • For luminaires of protection class I and protection class II
  • Adjustable output current between 250 and 700 mA via ready2mains Programmer or I-SELECT 2 plugs
  • Max. output power 100 W
  • Up to 95 % efficiency
  • Nominal lifetime up to 100,000 h
  • 5 years guarantee

Housing properties

  • Low profile metal casing with white cover
  • Type of protection IP20

Interfaces

  • ready2mains (configuration via mains)
  • Terminal blocks: 0° push terminals

Functions

  • Adjustable output current in 1-mA-steps (ready2mains, I-SELECT 2)
  • Protective features (overtemperature, short-circuit, overload, no-load, input voltage range)
  • Intelligent Voltage Guard (overvoltage and undervoltage monitoring)
  • Suitable for emergency escape lighting systems acc. to EN 50172

Benefits

  • Application-oriented operating window for maximum compatibility
  • Best energy savings due to high efficiency
  • Flexible configuration via ready2mains and I-SELECT 2
  • Reliability proven by lifetime up to 100,000 h and 5 years guarantee

Typical applications

  • For linear/area lighting in office applications

Driver LC 100W 250–700mA flexC lp EXC

Product form

SKU: LC100250700-TR
Barcode: 28000690

Stock Level: Ordered in - Delivery 2-3 Days

Trade price available - contact us

£22.09 Excl. VAT

(inc. 20% VAT): £26.51

    • Contact us to confirm availability
      Downloads

    Driver LC 100W 250–700mA flexC lp EXC excite series non-SELV Product description Constant current LED driver for luminaire installation For... Read more

    Description

    Driver LC 100W 250–700mA flexC lp EXC

    excite series non-SELV

    Product description

    • Constant current LED driver for luminaire installation
    • For luminaires of protection class I and protection class II
    • Adjustable output current between 250 and 700 mA via ready2mains Programmer or I-SELECT 2 plugs
    • Max. output power 100 W
    • Up to 95 % efficiency
    • Nominal lifetime up to 100,000 h
    • 5 years guarantee

    Housing properties

    • Low profile metal casing with white cover
    • Type of protection IP20

    Interfaces

    • ready2mains (configuration via mains)
    • Terminal blocks: 0° push terminals

    Functions

    • Adjustable output current in 1-mA-steps (ready2mains, I-SELECT 2)
    • Protective features (overtemperature, short-circuit, overload, no-load, input voltage range)
    • Intelligent Voltage Guard (overvoltage and undervoltage monitoring)
    • Suitable for emergency escape lighting systems acc. to EN 50172

    Benefits

    • Application-oriented operating window for maximum compatibility
    • Best energy savings due to high efficiency
    • Flexible configuration via ready2mains and I-SELECT 2
    • Reliability proven by lifetime up to 100,000 h and 5 years guarantee

    Typical applications

    • For linear/area lighting in office applications
