EIP009C0350LSD1L - Eaglerise Constant Current Triac Dimmable LED Driver 9W-350mA

Description

Eaglerise EIP009CLSD1L Series constant current, triac dimmable LED driver.

Output current 400mA 9W
Features: Short circuit, over load, over voltage & over temperature protection
IP20 rated
Power Factor 0.9
Efficiency 78% Class II, SELV Leading edge & trailing edge dimmable.
5 Year Warranty

More Information:
Manufacturer: Eaglerise
Output Wattage (W): 9
Output Current: 400mA
Dimmable (Type): Triac Leading edge & Trailing edge
DC Output Adjustment: No
Dimensions: 105 x 42 x 24 mm
EMC Standards: EN55015; EN61000-3-2 Class C; EN61000-3-3, EN 61547;EN 61000-4-2, Performance Criteria B; EN 61000-4-5, 1000V Performance Criteria C
Input Voltage: 220-240VAC
Safety Standards: EN 61347-1; EN61347-2-13
Output Voltage Options: Single
Working Temperature: -10 ~ +50C

EIP009C0350LSD1L - Eaglerise Constant Current Triac Dimmable LED Driver 9W-350mA

Product form

SKU: EUP12T-1HMC

Trade price available - contact us

£19.20 Excl. VAT

(inc. 20% VAT): £23.04

    • Contact us to confirm availability
      Downloads

    Eaglerise EIP009CLSD1L Series constant current, triac dimmable LED driver. Output current 400mA 9W Features: Short circuit, over load, over voltage & over temperature... Read more

    Description

    Eaglerise EIP009CLSD1L Series constant current, triac dimmable LED driver.

    Output current 400mA 9W
    Features: Short circuit, over load, over voltage & over temperature protection
    IP20 rated
    Power Factor 0.9
    Efficiency 78% Class II, SELV Leading edge & trailing edge dimmable.
    5 Year Warranty

    More Information:
    Manufacturer: Eaglerise
    Output Wattage (W): 9
    Output Current: 400mA
    Dimmable (Type): Triac Leading edge & Trailing edge
    DC Output Adjustment: No
    Dimensions: 105 x 42 x 24 mm
    EMC Standards: EN55015; EN61000-3-2 Class C; EN61000-3-3, EN 61547;EN 61000-4-2, Performance Criteria B; EN 61000-4-5, 1000V Performance Criteria C
    Input Voltage: 220-240VAC
    Safety Standards: EN 61347-1; EN61347-2-13
    Output Voltage Options: Single
    Working Temperature: -10 ~ +50C
