HID-PV C 70 /S CDM 220-240V 50/60Hz NG 9137006529

Description

HID-PV C 70 /S CDM 220-240V 50/60Hz NG - 85974400- Philips - PVC070SCDM

View Datasheet

General information

Type Version
ng
Lamp Type
CDM
Number of Lamps
1 piece/unit
Suitable For Outdoor Use
No
Number of Products on MCB (16A Type B) (Nom)
20
Automatic Restart
Yes

Operating and electrical

Input Voltage
220 to 240 V
Input Frequency
50 to 60 Hz
Operating Frequency (Nom)
0.14 kHz
Power Factor 100% Load (Nom)
0.95
Ignition Voltage (Max)
4.0 kV
Ignition Switch-Off Time (Nom)
18 min
Mains Voltage Performance (AC)
-10%-+6%
Mains Voltage Safety (AC)
-18%-+10%
Inrush Current Width
0.33 ms
Constant Wattage Deviation
-3%/+3%
Power Losses (Nom)
7.0 W
Inrush Current Peak (Max)
33 A
Efficiency at full load [%]
90.60000000000001 %

HID-PV C 70 /S CDM 220-240V 50/60Hz NG 9137006529

Product form

SKU: PVC70S-PH
Barcode: 8711500881694

Stock Level: Ordered in - Delivery 2-3 Days

Trade price available - contact us

£42.64 Excl. VAT

(inc. 20% VAT): £51.17

    • Contact us to confirm availability
      Downloads

    HID-PV C 70 /S CDM 220-240V 50/60Hz NG - 85974400- Philips - PVC070SCDM View Datasheet General information Type Version ng... Read more

    Description

    HID-PV C 70 /S CDM 220-240V 50/60Hz NG - 85974400- Philips - PVC070SCDM

    View Datasheet

    General information

    Type Version
    ng
    Lamp Type
    CDM
    Number of Lamps
    1 piece/unit
    Suitable For Outdoor Use
    No
    Number of Products on MCB (16A Type B) (Nom)
    20
    Automatic Restart
    Yes

    Operating and electrical

    Input Voltage
    220 to 240 V
    Input Frequency
    50 to 60 Hz
    Operating Frequency (Nom)
    0.14 kHz
    Power Factor 100% Load (Nom)
    0.95
    Ignition Voltage (Max)
    4.0 kV
    Ignition Switch-Off Time (Nom)
    18 min
    Mains Voltage Performance (AC)
    -10%-+6%
    Mains Voltage Safety (AC)
    -18%-+10%
    Inrush Current Width
    0.33 ms
    Constant Wattage Deviation
    -3%/+3%
    Power Losses (Nom)
    7.0 W
    Inrush Current Peak (Max)
    33 A
    Efficiency at full load [%]
    90.60000000000001 %
