HLG-120H-48B - Mean Well LED Driver HLG-120H-48B 120W 48V

Description

Built-in active PFC function, PF>0.9 for 60% of load or higherIP67 design for indoor or outdoor installationsProtections: Short circuit / Over current / Over voltage / Over temperatureOther features:Universal AC input (up to 305VAC) / Full rangeHigh efficiency up to 94% Output current adjustable through output cable or internal potentiometerCooling by free air convectionSuitable for dry, damp and wet locationSuitable for LED lighting and street lighting applicationsMeet 4KV surge immunity level (IEC61000-4-5)Multiple models for choice:Built-in 3 in 1 dimming function (1~10VDC, PWM signal, or resistance)5 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 120 Output Voltage 48V Dimmable (Type) 1-10VDC, PWM signal, resistance DC Output Adjustment -0 Dimensions 220 x 68 x 38.8 EMC Standards EN55015, EN55022, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, EN55024 Input Voltage 90~264VAC, 127~370VDC Safety Standards TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13 approved Output Voltage Options Single Working Temperature -40~+70°C PDF Datasheet HLG-120-spec_1.pdf

HLG-120H-48B - Mean Well LED Driver HLG-120H-48B 120W 48V

Product form

SKU: HLG-120H-48B

Trade price available - contact us

£80.20 Excl. VAT

(inc. 20% VAT): £96.24

    • Contact us to confirm availability
      Downloads

    Built-in active PFC function, PF>0.9 for 60% of load or higherIP67 design for indoor or outdoor installationsProtections: Short circuit /... Read more

    Description

    Built-in active PFC function, PF>0.9 for 60% of load or higherIP67 design for indoor or outdoor installationsProtections: Short circuit / Over current / Over voltage / Over temperatureOther features:Universal AC input (up to 305VAC) / Full rangeHigh efficiency up to 94% Output current adjustable through output cable or internal potentiometerCooling by free air convectionSuitable for dry, damp and wet locationSuitable for LED lighting and street lighting applicationsMeet 4KV surge immunity level (IEC61000-4-5)Multiple models for choice:Built-in 3 in 1 dimming function (1~10VDC, PWM signal, or resistance)5 years warranty
    More Information Manufacturer Mean Well Output Wattage (W) 120 Output Voltage 48V Dimmable (Type) 1-10VDC, PWM signal, resistance DC Output Adjustment -0 Dimensions 220 x 68 x 38.8 EMC Standards EN55015, EN55022, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, EN55024 Input Voltage 90~264VAC, 127~370VDC Safety Standards TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13 approved Output Voltage Options Single Working Temperature -40~+70°C PDF Datasheet HLG-120-spec_1.pdf
