LPV-60-24 - Mean Well 60W 24V LED Driver LPV-60-24

Description

Constant Voltage Fully encapsulated with IP67 level

Protections: Short circuit/ Overload/ Over voltage
Other features: Universal AC input / Full Range Class 2 power unit Isolation class II, no F.G. Withstand 300VAC surge input for 5 seconds
Cooling by free air convection
Pass LPS 100% full load burn-in test Low cost,
High reliability 2 years warranty

More Information:
Manufacturer: Mean Well
Output Wattage (W) 60
Output Voltage 24V
Dimmable (Type) No
DC Output Adjustment N/A
Dimensions 162.5 x 42.5 x 32
EMC Standards EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11
Input Voltage 90~264VAC
Safety Standards UL1310, UL879 approved;
Design refer to TUV EN60950-1, EN61347-2-13
Output Voltage Options Single
Working Temperature -30°C~+70°C

LPV-60-24 - Mean Well 60W 24V LED Driver LPV-60-24

Product form

SKU: LPV-60-24

Trade price available - contact us

£25.00 Excl. VAT

(inc. 20% VAT): £30.00

    • Contact us to confirm availability
      Downloads

    Constant Voltage Fully encapsulated with IP67 level Protections: Short circuit/ Overload/ Over voltage Other features: Universal AC input / Full... Read more

    Description

    Constant Voltage Fully encapsulated with IP67 level

    Protections: Short circuit/ Overload/ Over voltage
    Other features: Universal AC input / Full Range Class 2 power unit Isolation class II, no F.G. Withstand 300VAC surge input for 5 seconds
    Cooling by free air convection
    Pass LPS 100% full load burn-in test Low cost,
    High reliability 2 years warranty

    More Information:
    Manufacturer: Mean Well
    Output Wattage (W) 60
    Output Voltage 24V
    Dimmable (Type) No
    DC Output Adjustment N/A
    Dimensions 162.5 x 42.5 x 32
    EMC Standards EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11
    Input Voltage 90~264VAC
    Safety Standards UL1310, UL879 approved;
    Design refer to TUV EN60950-1, EN61347-2-13
    Output Voltage Options Single
    Working Temperature -30°C~+70°C
