Product family features
DC mode functionality
Type of protection: IP66 and IP67
Surge protection: up to 4 kV (L-N) / 6 kV (L/N-PE)
Wide operating temperature range: -30…+55 °C
Lifetime: up to 50,000 h (temperature at max. tc )
Product family benefits
Large range of products from 20 W to 250 W
Installation in very cold and hot environments
Very stable output power
High electronical reversible short-circuit, overload, overtemperature protection
Smart Power Supply: boosting power to turn on cold LEDs
Independent installation possible
Areas of application
Facades, public squares, cruise ships
Signage
Suitable for indoor and outdoor installations
Ecodesign regulation information:
Intended for use with LED modules.
The forward voltage of the LED light source shall be within the defined operating window of the control gear in all operating conditions including dimming if applicable.
Separate control gear and light sources must be disposed of at certified disposal companies in accordance with Directive 2012/19/EU (WEEE) in the EU and with Waste Electrical and Electronic Equipment (WEEE) Regulations 2013 in the UK. For this purpose, collection points for recycling centres and take-back systems (CRSO) are available from retailers or private disposal companies, which accept separate control gear and light sources free of charge. In this way, raw materials are conserved and materials are recycled.
