Xitanium 36W/m 0.3-1.05A 54V 230V

Description

Specifications  929002101206

General information
Protection class IEC
Safety class I/II

Operating and electrical
Output Current Ripple (Max)
4 %
Output Current (Max)
1050 mA
Open Circuit Voltage (DC) (Max)
60 V
Output Power (Max)
36 W
Output Power (Min)
11 W
Output Current (Min)
300 mA
Output Voltage (Max)
54 V
Output Voltage (Min)
24 V
System characteristics
Central DC Operation
Yes
YellowDot ready
No
Temperature
T-Case Lifetime (Max)
80 °C
T-Case Maximum (Max)
80 °C
Controls and dimming
Dimmable
No

Mechanical and housing
Product Length
97 mm
Housing
Mini 97x43x30 2p2p
Housing Dimensions
97.2 x 43 x 30
Overall length
97.2 mm
Overall width
43 mm
Overall height
30 mm
Approval and application
IP Classification
IP20  [ Finger-protected]
Isolation Classification
Class I and Class II
Approval Marks

CE marking

CB Certificate

ENEC certificate

CCC certificate

RCM compliance
Output Current Set Options
NFC
Product data
Full product code
871869964976000
Order product name
Xitanium 36W/m 0.3-1.05A 54V 230V
EAN/UPC - Product
8718699649760
Order code
929001486006
Numerator - Quantity Per Pack
1
Numerator - Packs per outer box
20
Material Nr. (12NC)
929001486006
Net Weight (Piece)
0.100 kg

Xitanium 36W/m 0.3-1.05A 54V 230V

Product form

SKU: XIT36-3105A54-PH
Barcode: 929002101206

Stock Level: Ordered in - Delivery 2-3 Days

Trade price available - contact us

£38.02 Excl. VAT

(inc. 20% VAT): £45.62

    • Contact us to confirm availability
      Downloads

    Specifications  929002101206 General information Protection class IEC Safety class I/II Operating and electrical Output Current Ripple (Max) 4 % Output... Read more
