Driver LC 150W 24V bDW SC PRE2 premium series 24 V – dimmable (IP20) With strain-relief Product description NEW: lumDATA (Luminaire data, Energy reporting and Diagnostics & Maintenance) Dimmable 24 V constant voltage LED driver for flexible constant voltage strips Can bei either used built-in or independent with clip-on strain-relief (see data sheet chapter: 1. Standards) The strain relief is included in both packaging variants. In the single packaging (SP) each Driver has also an individual packaging. basicDIM Wireless enables different dimming options Forms automatically a wireless communication network with up to 250 nodes Dimming range 1 to 100 % No additional external dimmer is needed Suitable for emergency escape lighting systems acc. to EN 50172 Nominal lifetime up to 50,000 h 5 years guarantee Typical applications Cove lighting, facade accent lighting, ceiling integration Technical details 24 V, 150 W Small design (325 x 43 x 30 mm) with stretched-compact strain relief Small cross section Push terminals for simple wiring Output terminals (+/–) equipped twice for more flexibility in the application Interfaces basicDIM Wireless ready2mains (configuration via mains) Terminal blocks: 45° push terminals System solution Tridonic LLE-FLEX ADV 600, 1,200, 1,800 lm/m Tridonic LLE-FLEX EXC 600, 1,200, 1,800, 2,500 lm/m In connection with Flex accessories wire to PCB plug Test the function of third party light sources before use at low dimming levels to ensure the dimming function works perfectly   Data sheet

Read more less

Driver LC 15W 300/350mA fixC SC SNC2 essence series Product description Fixed output LED driver Can be either used built-in or independent with clip-on strain-relief (see accessory) Independent LED driver with cable clamps Constant current LED driver For luminaires of protection class II Temperature protection as per EN 61347-2-13 C5e Output current 300 or 350 mA Max. output power 15 W Nominal lifetime up to 50,000 h 5 years guarantee Housing properties Casing: polycarbonate, white Type of protection IP20 Functions Overload protection Short-circuit protection No-load protection Burst protection voltage 1 kV Surge protection voltage 0.5 kV (L to N) Surge protection voltage 1 kV (L/N to earth) Typical applications For spot light and downlight in retail and hospitality applications For panel light and area light in office and education application

Read more less

Product description Dimmable constant current LED driver (SELV) Independent driver with strain-relief housing Extra flat housing for constrained installation conditions (small ceiling cut outs and low ceiling voids) Dimmable via leading edge and trailing edge phase dimmers Trailing edge is a benefit in terms of noise compared to leading edge Dimming range 5 to 100 % (depending on dimmer) For luminaires with F or M and MM as per EN 60598, VDE 0710 and VDE 0711 Max. output power 14.7 W Output current 350 mA Nominal lifetime up to 50,000 h 5 years guarantee (conditions at https://www.tridonic.com/manufacturer-guarantee-conditions)

Read more less

Driver LC 15W 350mA fixC pc SR SNC2 essence series Product description Dimmable constant current LED driver (SELV) Independent driver with strain-relief housing Extra flat housing for constrained installation conditions (small ceiling cut outs and low ceiling voids) Dimmable via leading edge and trailing edge phase dimmers Dimming range 5 to 100 % (depending on dimmer) For luminaires with F or M and MM as per EN 60598, VDE 0710 and VDE 0711 Max. output power 14.7 W Output current 350 mA Nominal lifetime up to 50,000 h 5 years guarantee Housing properties Casing: polycarbonate, white Type of protection IP20 Push-in terminals 2 separate strain relief parts for input and output cables with highly robust clamps Functions Overload protection Short-circuit protection No-load protection No output current overshoot at mains on/off

Read more less

Driver LC 15W 300/350mA fixC SR SNC2 Compact drivers Data sheet Product description Independent driver with strain-relief housing Extra flat housing for constrained installation conditions (small ceiling cut outs and low ceiling voids) For luminaires with M and MM as per EN 60598, VDE 0710 and VDE 0711 Temperature protection as per EN 61347-2-13 C5e Output current 300 or 350 mA Max. output power 15 W Nominal lifetime up to 50,000 h 5 years guarantee (conditions at https://www.tridonic.com/manufacturer-guarantee-conditions)

Read more less

Product description Constant current LED driver Can be either used built-in or independent with clip-on strain-relief (see accessory) Adjustable output current between 250 and 700 mA via ready2mains Programmer or I-SELECT 2 plugs Max. output power 17 W Up to 86 % efficiency Nominal lifetime up to 100,000 h 5 years guarantee Housing properties Casing: polycarbonate, white Type of protection IP20 Interfaces ready2mains (configuration via mains) Terminal blocks: 45° push terminals Functions Adjustable output current in 1-mA-steps (ready2mains, I-SELECT 2) Protective features (overtemperature, short-circuit, overload, no-load, input voltage range) Intelligent Voltage Guard (overvoltage and undervoltage monitoring) Suitable for emergency escape lighting systems acc. to EN 50172 Benefits Application-oriented operating window for maximum compatibility Best energy savings due to high efficiency Flexible configuration via ready2mains and I-SELECT 2 Typical applications For downlight, spotlight and decorative applications

Read more less

Obsolete , please order 28002472  Driver LC 19W 350mA fixC lp SNC2 Linear drivers Data sheet Product description Fixed output built-in LED driver Constant current LED driver For luminaires of protection class I and protection class II Temperature protection as per EN 61347-2-13 C5e Output current 350 mA Max. output power 18.9 W Up to 88 % efficiency Nominal lifetime up to 50,000 h 5 years guarantee (conditions at www.tridonic.com)

Read more less

Product description Independent constant current LED driver Output current adjustable between 100 – 1,050 mA with NFC Max. output power 20 W Up to 81 % efficiency Nominal lifetime up to 100,000 h 5 years guarantee Housing properties Casing: polycarbonate, white Type of protection IP20 Toolless mounting of strain relief Interfaces Near field communication (NFC) Functions Adjustable output current in 1-mA-steps (NFC) Protective features (overtemperature, short-circuit, overload, no-load) Surge protection voltage 1 kV (L – N) Suitable for emergency escape lighting systems acc. to EN 50172 For cable cross-sections up to 2.5 mm² Benefits Flexible configuration via companionSUITE (NFC) Application-oriented operating window for maximum compatibility New strain relief concept – fast mounting and pre-assembled connection of the LED load possible Typical applications For applications in downlight and decorative luminaires

Read more less

Driver LC 20W 100-1050mA 44V o4a NF SR EXC3 excite series Product description Independent constant current LED driver Dimmable via DALI-2 Dimming range 1 to 100 % (min. 5 mA) Output current adjustable between 100 – 1,050 mA with DALI or NFC Max. output power 20 W Up to 85 % efficiency Power input on stand-by < 0.4 W Nominal lifetime up to 100,000 h 5 years guarantee Housing properties Casing: polycarbonate, white Type of protection IP20 Toolless mounting of strain relief Interfaces Near field communication (NFC) one4all (DALI-2 DT 6, switchDIM, corridorFUNCTION V2) Functions Adjustable output current in 1-mA-steps (NFC, DALI-2) Constant light output function (CLO) Protective features (overtemperature, short-circuit, overload, no-load) Surge protection voltage 1 kV (L – N) Suitable for emergency escape lighting systems acc. to EN 50172 For cable cross-sections up to 2.5 mm² Benefits Flexible configuration via companionSUITE (NFC, DALI-2) Application-oriented operating window for maximum compatibility New strain relief concept – fast mounting and pre-assembled connection of the LED load possible Typical applications For applications in downlight and decorative luminaires

Read more less

Product description Independent fixed output LED Driver For luminaires of protection class I and protection class II For luminaires with M and MM as per EN 60598, VDE 0710 and VDE 0711 Temperature protection as per EN 61347-2-13 C5e Selectable output current between 350, 500 and 700 mA Max. output power 20 W Up to 85 % efficiency Nominal lifetime up to 50,000 h 5 years guarantee Housing properties Casing: polycarbonate, white Type of protection IP20 Interfaces Terminal blocks: 0° screw terminals Functions Overload protection Short-circuit protection No-load protection Overtemperature protection Burst protection voltage 1 kV Burst protection voltage 1 kV (L to N) Surge protection voltage 2 kV (L/N to earth) Typical applications For spot light and downlight in retail and hospitality applications For panel light and area light in office and education application

Read more less

This item is now obsolete  Driver LC 20W 350mA fixC C SNC essence series Product description Fixed output built-in LED driver Constant current LED driver For luminaires of protection class I and protection class II Temperature protection as per EN 61347-2-13 C5e Output current 350 mA Max. output power 18.9 W Nominal lifetime up to 50,000 h 5 years guarantee Housing properties Casing: polycarbonate, white Type of protection IP20 Functions Overload protection Short-circuit protection No-load protection Burst protection voltage 1 kV Surge protection voltage 1 kV (L to N) Surge protection voltage 2 kV (L/N to earth)

Read more less

Driver LC 25W 250/300/350mA fixC lp SNC2 Linear drivers Data sheet Product description Fixed output built-in LED driver Constant current LED driver For luminaires of protection class I and protection class II Temperature protection as per EN 61347-2-13 C5e Output current 250, 300 or 350 mA Max. output power 25 W Up to 88 % efficiency Nominal lifetime up to 50,000 h 5 years guarantee (conditions at www.tridonic.com)

Read more less
