Electronic ballast with highest possible energy class CELMA EEI A2 BAT. It offers large temperature range, intelligent voltage guard, precise lamp operation using adjustment of lamp parameters, advanced SMART-Heating for minimum 50000 starts without replacement of lamps, constant luminous flux irrespective of fluctuations in mains voltage, designed for THD <10%, for luminaires of protection class I and protection class II. It features automatic start after replacement of defective lamps, safety shutdown of defective lamps and at end of lamp life (EOL 2), insulation displacement connection (IDC) terminal for rapid automatic or manual wiring and for emergency lighting systems as per EN 50172.
· Rated lifespan: 100,000 hours
· Flicker free warm start
· Min/Max ambient working temperature: -25°C to 70°C
· Degree of protection: IP20
· Operating voltage: 198-264V (AC), 176-280V (DC)
Obsolete , you will be sent the below
https://www.easy-controlgear.com/products/tridonic-pc126basicsl-tr-1x26-tcd-1-x-26w-tct-slim-basic-ballast?_pos=2&_sid=a8b496c0b&_ss=r
Tridonic PC128DDPRO Electronic HF ballast to run 1 x 28w Compact DD lamps
echnical Specifications
Accessory Type
Ballast
Wattage
50/80 W
Manufacturer
Vossloh Schwabe
Dimming?
Non-Dimmable
Depth
66 mm
Length
108 mm
Type
Control Gear
Number of Lamps
1
Voltage
220-240 Volt
Width
53 mm
Control Gear Technology
Discharge
Manufacturers Part Number
Q80/50.551
An alternative will be offered
https://www.easy-controlgear.com/products/ln18i-319-163763-vossloh-schawbe?_pos=1&_sid=46c6cc7ad&_ss=r
Please note the alternative is 105mm wide
1x18w T8 Magnetic Ballast 85x28x42mm - Helvar - L18D
PLEASE READ
DTSE5-11-S-OS
5/7/9/11w ballast C/w G23 Holder - Vossloh Schwabe - L7/9/11.141
These are obsolete , however we can supply a electronic ballast suitable for a 4 pin lamp .( see secondary picture) Included in the price will be a 4 pin lamp please select which wattage you currently have. We will supply in colour 4000K unless you call to advise otherwise
Tridonic PC3414T5PRO Electronic ballast to run 3/4 x 14w T5 tubes - 22176315/22185211
Specifications
Attribute
Value
Wattage
14 W
Ballast Type
Electronic
Supported Lamp Shape
T5
Supported Lamp Type
Fluorescent
Voltage Rating
220 → 240 V
Dimmable
No
High Frequency
Yes
Length
360 mm
Width
30 mm
Height
21mm
Minimum Operating Temperature
-25°C
Maximum Operating Temperature
+60°C
EU Energy Efficiency Rating
A2
Obsolete, If using with water treatment lamps please consider the below as a viable alternative.
Possible Alternative
Linear Electronic ballast T8, 2 x 15/18W, 110-260v
