ELED-360-24DP2 - Ecopac ELED-360-D Series LED Driver 360W 24V (DALI2 & Push Dimming)

Description

Ecopac ELED-360-D series constant voltage LED driver. DALI and Push dimmable Constant voltage / PWM Output DALI & Push dimming function AC input: 100-265VAC Built-in active PFC function Efficiency up to 91.2% Protections: Short circuit / Over load / Over temperature Cooling by free air convection IP66 design for indoor and outdoor installation Suitable for intelligent LED lighting
More Information Manufacturer Ecopac Power Output Wattage (W) 360 Output Voltage Choose Option Dimmable (Type) DALI, Push Dimming Dimensions 276 x 78 x 47mm EMC Standards Safety According to EN61000-4-2,3,4,5,6,11, EN61547, EN55015, EN61000-3-2, 3 (>60%load) Input Voltage 100-265VAC Safety Standards EN61347-1, EN61347-2-13, IP66 Output Voltage Options Single Working Temperature -40 ~ +60°C PDF Datasheet ELED-360-D.pdf

ELED-360-24DP2 - Ecopac ELED-360-D Series LED Driver 360W 24V (DALI2 & Push Dimming)

Product form

SKU: ELED-360-24DP2

Trade price available - contact us

£186.80 Excl. VAT

(inc. 20% VAT): £224.16

    • Contact us to confirm availability
      Downloads

    Ecopac ELED-360-D series constant voltage LED driver. DALI and Push dimmable Constant voltage / PWM Output DALI & Push dimming function... Read more

    Description

    Ecopac ELED-360-D series constant voltage LED driver. DALI and Push dimmable Constant voltage / PWM Output DALI & Push dimming function AC input: 100-265VAC Built-in active PFC function Efficiency up to 91.2% Protections: Short circuit / Over load / Over temperature Cooling by free air convection IP66 design for indoor and outdoor installation Suitable for intelligent LED lighting
    More Information Manufacturer Ecopac Power Output Wattage (W) 360 Output Voltage Choose Option Dimmable (Type) DALI, Push Dimming Dimensions 276 x 78 x 47mm EMC Standards Safety According to EN61000-4-2,3,4,5,6,11, EN61547, EN55015, EN61000-3-2, 3 (>60%load) Input Voltage 100-265VAC Safety Standards EN61347-1, EN61347-2-13, IP66 Output Voltage Options Single Working Temperature -40 ~ +60°C PDF Datasheet ELED-360-D.pdf
