90W 24V CONSTANT VOLTAGE MAINS DIMMABLE LED DRIVER
ELED-90P T Series Features:
Works with leading edge and trailing edge TRIAC dimmers
PWM Output
Output constant voltage
Other features:
High efficiency up to 86%
Protections: Short circuit/over loading/over temperature/Over Current
Cooling by free air convection
IP20 design for outdoor installation
3 years warranty
0-10V/ Potentiometer/ 10V PWM dimmableConstant voltage designProtections: Short circuit/ Overload/ Over Voltage/ Over TemperatureOther features:Universal AC input/ Full rangeIP66 design for indoor or outdoor installationsBuilt-in PFC functionCooling by free air convection85% efficiency3 years warrantyMore Information
Manufacturer
Ecopac Power
Output Wattage (W)
200
Output Voltage
24V
Dimmable (Type)
0-10V, Potentiometer, 10V PWM dimmable
Dimensions
256x 80x 53
EMC Standards
Compliance to EN55015, EN61000-3-2 (>50% load) Compliance to EN61000-4-2,3,4,5,6,8,11, EN61547, A light industry level
Input Voltage
100-265VAC
Safety Standards
EN61347-1-12 IP66
Output Voltage Options
Single
Working Temperature
-40~+60°C
PDF Datasheet
ELED-180-200V-Series.pdf
ELED-300-12V 300W/360W 0/1-10V Dimmable LED Driver
Features:• Three in one dimming function (0/10Vdc orPWM signal or resistance)• Output constant voltage• AC input 100-265VAC• High efficiency up to 91%• Protections: Short circuit/over loading/overcurrent• Cooling by free air convection• Built-in active PFC function• 5 years warranty
Ecopac EPV-60P-12 Non-dim Constant Voltage LED Drivers 60W
The EPV-60P-XX series is a 60W, constant-Voltage IP67 LED driver that operates from 176-264Vac input with excellent power factor and THD feature.
Feature:
High efficiency up to 89%
Built-in active PFC function
All-Around Protection: OLP,SCP,OTP
Compact plastic Case, Free Air Convection
Waterproof(IP67) and UL Dry/Damp/Wet Location
Input Surge Protection:2kV line-line
High Reliability & Long Lifetime & 5 Years Warranty
Constant voltage/ PWM Output• Leading & Trailing edge dimmable• AC input: 200-240VAC• Built-in active PFC function• Efficiency up to 87%• Protections: Short circuit/ Over loading/ Over current/ Over temperature• Full protection aluminium housing• Cooling by free air convection• Suitable for LED lighting and moving signs
The Ecopac Power ECP150-12VF-1 slimline constant voltage LED driver is ideal for concealment where space is restricted, such as hiding behind a strip. Short circuit, over temperature and over loading protection are all standard features. Ecopac Power LED Drivers are supplied with a 3 year warranty. Other features: Slim line LED Driver Universal AC input/ Full range 180-264VAC Input Frequency 50/60Hz 12V Constant voltage output 3 years warrantyMore Information Manufacturer Ecopac Power Output Wattage (W) 150 Output Voltage 24V Dimmable (Type) No DC Output Adjustment N/a EMC Standards EN55015, EN61000-3-2; EN61000-4-2,3,4,5,6 EN61547 Input Voltage 180-264VAC Safety Standards EN61347-1,EN61347-2-13 Working Temperature -20~+45°C
Constant current designIP66 ratedProtections: Short circuit/ Overload/ Over temp.Input Voltage: 100 – 240VACCooling by free air convectionLow cost, high reliabilityOutput Power: 4WCompact and light-weight plastic caseWorking Temperature: 0°C to +45°C2 year warrantyMore Information
Manufacturer
Ecopac Power
Output Wattage (W)
10
Output Current
500mA
Dimmable (Type)
No
Output Voltage Range (V)
9.5 Max
Dimensions
38x 30x 23.5
EMC Standards
EN55015, EN61000-3-2, EN61000-3-3, EN61547
Input Voltage
100~240VAC
Safety Standards
EN61347-1, EN61347-2-13
Output Voltage Options
Single
Working Temperature
-40~+85°C
PDF Datasheet
ECP4-ILP.pdf
Constant current designIP66 ratedProtections: Short circuit/ Overload/ Over temp.Input Voltage: 100 – 240VACCooling by free air convectionLow cost, high reliabilityOutput Power: 4WCompact and light-weight plastic caseWorking Temperature: 0°C to +45°C3 year warrantyMore Information
Manufacturer
Ecopac Power
Output Wattage (W)
7
Dimmable (Type)
No
Dimensions
38x 30x 23.5
EMC Standards
EN55015, EN61000-3-2, EN61000-3-3, EN61547
Input Voltage
100~240VAC
Safety Standards
EN61347-1, EN61347-2-13
Output Voltage Options
Single
Working Temperature
-40~+85°C
PDF Datasheet
ECP4-ILP.pdf
