ELED-40-C300/1400DP2 DALI Dimmable Constant Current LED Drivers 19.5–40W

Description

ELED-40-C300/1400DP2 Features:

40W DALI 2 and Push Dimming Multiple-Stage Output Current LED Driver

Features:

• Constant Current mode output with multiple levels selectable by dip switch
• DALI 2 dimming function (IEC62386)
• AC input: 100-277VAC
• Built-in active PFC function
• Efficiency up to 86%
• Protections: Short circuit/ Over load/Over temperature
• Cooling by free air convection
• Suitable for intelligent LED lighting

Wattage 40 40 40 40 40 40 40 40 40 39 35.8 32.5 29.3 26 22.8 19.5
Input Voltage 100~277VAC 100~277VAC 100~277VAC 100~277VAC 100~277VAC 100~277VAC 100~277VAC 100~277VAC 100~277VAC 100~277VAC 100~277VAC 100~277VAC 100~277VAC 100~277VAC 100~277VAC 300mA
Output Current 1400mA 1300mA 1200mA 1100Ma 1000mA 900mA 800mA 700mA 650mA 600mA 550mA 500mA 450mA 400mA 350mA 3~65
Output Voltage 3~29 3~31 3~34 3~37 3~40 3~45 3~50 3~57 3~62 3~65 3~65 3~65 3~65 3~65 3~65
Dimensions 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm
Working Temperature -40~80°C
Safety Standards EN61347-1, EN61347-2-13, UL8750
EMC Standards Compliance to EN55015, EN61000-3-2,3 (≥50% load), FCC Part 15B

ELED-40-C300/1400DP2 DALI Dimmable Constant Current LED Drivers 19.5–40W

Product form

SKU: ELED-40-C300/1400D

Stock Level: Ordered in - Delivery 2-3 Days

Trade price available - contact us

£63.18 Excl. VAT

(inc. 20% VAT): £75.82

    • Contact us to confirm availability
