ELED-75-24D - Ecopac ELED-75-24D DALI Dimmable LED Driver 75W 24V

Description

Obsolete

Alternative Up to 100W

Alternative up to 60W



The Ecopac ELED-75-24D DALI Dimmable LED Driver is 75W 24VDC output.  Constant Voltage  / PWM Output Design Dali & Push Dimmable Protections: Short circuit/ Over Voltage/ Over Temperature Other features: Dimming range from 0.1% to 100% Input Range 200-265VAC Output 24VDC Built-in PFC function IP20design for indoor or outdoor installations 87% efficiency 3 years warranty
More Information Manufacturer Ecopac Power Output Wattage (W) 75 Output Voltage 24V Dimmable (Type) DALI, Push Dimming DC Output Adjustment No Dimensions 355 x 215 x 215 mm EMC Standards Compliance to EN55015, EN61000-3-2, EN61000-3-3 (?60% load), EN61000-4-2,3,4,5,6,11, EN61547 Input Voltage 100-265VAC Safety Standards EN61347-1, EN61347-2-13, EN62493, IP20 Output Voltage Options Single Working Temperature -40 ~ +60°C PDF Datasheet ELED-75-D.pdf

ELED-75-24D - Ecopac ELED-75-24D DALI Dimmable LED Driver 75W 24V

Product form

SKU: ELED-75-24D

Trade price available - contact us

£73.49 Excl. VAT

(inc. 20% VAT): £88.19

    • Contact us to confirm availability
      Downloads

    Obsolete Alternative Up to 100W Alternative up to 60W   The Ecopac ELED-75-24D DALI Dimmable LED Driver is 75W 24VDC... Read more

    Description

    Obsolete

    Alternative Up to 100W

    Alternative up to 60W



    The Ecopac ELED-75-24D DALI Dimmable LED Driver is 75W 24VDC output.  Constant Voltage  / PWM Output Design Dali & Push Dimmable Protections: Short circuit/ Over Voltage/ Over Temperature Other features: Dimming range from 0.1% to 100% Input Range 200-265VAC Output 24VDC Built-in PFC function IP20design for indoor or outdoor installations 87% efficiency 3 years warranty
    More Information Manufacturer Ecopac Power Output Wattage (W) 75 Output Voltage 24V Dimmable (Type) DALI, Push Dimming DC Output Adjustment No Dimensions 355 x 215 x 215 mm EMC Standards Compliance to EN55015, EN61000-3-2, EN61000-3-3 (?60% load), EN61000-4-2,3,4,5,6,11, EN61547 Input Voltage 100-265VAC Safety Standards EN61347-1, EN61347-2-13, EN62493, IP20 Output Voltage Options Single Working Temperature -40 ~ +60°C PDF Datasheet ELED-75-D.pdf
