EM PowerLED 1w PRO EZ-3 89800031

Product description
_ Emergency lighting LED driver with DALI interface and automatic
test function
_ For self-contained emergency lighting
_ SELV for output voltage < 60 V DC
_ Low profile casing (21 x 30 mm cross-section)
_ EM = Emergency
_ 5 years guarantee (conditions at
https://www.tridonic.com/en/int/services/manufacturerguarantee-conditions)
Properties
_ Mains and emergency operation
_ DALI interface for controlled testing and monitoring
_ DALI switchable in mains operation (on/off); the switched phase
SL must be switched on
_ Constant current mode
_ With either screw or clip fastening (clip-fix)
_ 1, 2 or 3 h rated duration
_ Selectable operating time (jumper)
_ Output power limitation
_ Two-colour status display LED
_ Automatic restart after LED replacement
_ Electronic multi-level charge system
_ SELV classified (outputs powerLED, battery, status LED, test
switch)
_ Polarity reversal protection for battery
_ Deep discharge protection
_ Very low energy consumption from the battery after activation of
the deep discharge protection
_ Short-circuit-proof battery connection
_ Addressing function, patented (“EZ easy addressing”)
_ Emergency lighting LEDs available
 Tests:
_ Status of the battery
_ Status of the LED
_ Charge condition
_ Function test
_ Duration test
Batteries
_ High-temperature cells 2 Ah
_ NiMH batteries
_ Cs cells
_ NiMH: 4 years design life / 2 years guarantee (conditions at
https://www.tridonic.com/en/int/services/manufacturerguarantee-conditions)
_ For battery compatibil
