Name: HF-R 236 TL-D EII 220-240V 50/60Hz 1-10V Dimmable 2 x 36W
Brand: PHILIPS
SKU: HFR236TLDEII-PH
Price: 53.34 GBP

HF-R 236 TL-D EII 220-240V 50/60Hz 1-10V Dimmable 2 x 36W

PHILIPS
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

HF-R 236 TL-D EII 220-240V 50/60Hz 1-10V Dimmable 2 x 36W

PHILIPS
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Product form

SKU: HFR236TLDEII-PH
Barcode: 8711500910158

Trade price available - contact us

£53.34 Excl. VAT

(inc. 20% VAT): £64.01

Contact us to confirm availability

Downloads

General Information Remarks UK importer address: Signify Commercial UK Limited, 3, Guildford Business Park, GU2 8XG Application code EII Type... Read more

Number of lamps	2 piece/unit
Number of products on MCB (16 A type B) (nom.)	12
Automatic restart	Yes

Input Voltage	220 to 240 V
Input frequency	50 to 60 Hz
Operating frequency (max.)	89 kHz
Operating frequency (min.)	45 kHz
Ignition method	Programmed Start
Crest factor (max.)	1.7
Power factor 100% load (nom.)	0.98
Ignition time (max.)	0.2 s

Mains voltage performance (AC)	-8%-+6%
Mains voltage safety (AC)	-10%-+10%
Earth leakage current (max.)	0.5 mA
Inrush current width	0.40 ms
Power losses (nom.)	7.3 W
Inrush current peak (max.)	45 A
Efficiency at full load [%]	88.69 %

Number of lamps	2 piece/unit
Number of products on MCB (16 A type B) (nom.)	12
Automatic restart	Yes
