roduct family features
Dimmable via Touch DIM
50 m load cable with EMI validated
Dimming range: 0.1…100 %
Line frequency: 0 Hz | 50 Hz | 60 Hz
Product family benefits
Intelligent power matching thanks to Smart power supply
Form factor for mounting on the cove or in luminaires
No stroboscopic effect thanks to patented high PWM frequency management (> 2 kHz)
Suitable for installation in emergency lighting systems according to EN 60598-2-22
DALI message detection "LED Module failure"
DALI part 251-252-253
IP rating: IP20
Areas of application
Cove lighting, wall washer, corridor, handrail, luminous ceilings
Suitable for use in luminaires of protection class I and II
Equipment / Accessories
Suitable for 48 V LED modules
Ecodesign regulation information:
Intended for use with LED modules.
The forward voltage of the LED light source shall be within the defined operating window of the control gear in all operating conditions including dimming if applicable.
Separate control gear and light sources must be disposed of at certified disposal companies in accordance with Directive 2012/19/EU (WEEE) in the EU and with Waste Electrical and Electronic Equipment (WEEE) Regulations 2013 in the UK. For this purpose, collection points for recycling centres and take-back systems (CRSO) are available from retailers or private disposal companies, which accept separate control gear and light sources free of charge. In this way, raw materials are conserved and materials are recycled.
