The Osram QTi 2x21/39/220-240 DIM is a 1-10v intelligent dimmable ballast to run 2 x 21w or 39w T5 Tubes. These ballasts have an average life of 100,000 hours, offer flicker free light, have an automatic safety shutdown at lamp failure, automatic restart after lamp replacement and are suitable for emergency lighting.

Read more less

  This item no longer available please consider the below item as a viable alternative   Alternative    1x39w TL5 1-10v Analogue Dimming Ballast - HFR139TL5E11 - 91468230

Read more less

The Helvar EL ngn 2x18 is a non dimmable high frequency ballast is to run 2 x 18w T8 or PLL  fluoresent tube.Long life time, Low cost in operation this means they have a smaller environmental impact.

Read more less

2 x 26-32w Quicktronic Ballast ECG

Read more less

Tridonic PC140TCLPRO Electronic Bllast to run 1 x 40w PLL lamps - PC 1/40 TCL PRO - 22176142 / 87500508

Read more less

The ELT BE-436-2 is a non dimmable high frequency ballast to run: 3 or 4 x 18/30/36w T8 Fluorescent Tubes, 18/36w long single turn compact fluorescent tubes or 24w T5 Fluorescent Tubes. This ballast can also be used to run 3 x 39w T5 fluorescent tubes.   Product Details 3 & 4 Lamp Electronic Ballast ELT 3 & 4 lamp electronic high frequency ballasts for controlling T8 / TC-L / T5 fluorescent lamps. BE 436-2 ballasts con be connected to three or four lampsModel BE 436 is designed with independent lampsClass I ballast for built-in useIgnition with preheating in cathodes for a long life in the lamp, without flashes or flickeringConstant total power and stabilized luminous fluxHigh frequency operationHigh energy efficiencyCorrected stroboscopic effectAllows the use of Class I and Class II luminaires without screening to earth in the lampsPermitted voltage 198-264V, 50-60HzSupports 2 hours at 350V (A/C)Rapid connection connector with fixing spring. Circular conductor section: 0.5-1.5 mm2 Standards EN 61347-1-2-3, EN 60929, EN 61000-3-2, EN 55015, EN 61547. Specifications Attribute Value Wattage 18 W, 24 W, 30 W, 36 W, 39 W Ballast Type Electronic Supported Lamp Shape T5, T8, TC-L Supported Lamp Type Compact Fluorescent, Fluorescent Voltage Rating 220 → 240 V Dimmable No High Frequency Yes Length 360 mm Height 28mm Minimum Operating Temperature -20°C Maximum Operating Temperature +50°C

Read more less

VOSSLOH NAH 100.941 161707 SON/MH 230V 50Hz from Vossloh Schwabe Model: 100.941 A Vossloh Schwabe branded ballast that has been designed to operate high pressure sodium and metal halide lamps. It can output up to 100W (230-240V). It has screw terminals that can handle cables between 0.5mm and 2.5mm in diameter and has an ebergy efficiency rating of EEI=A3.   Technical Specifications Control Gear Type Switch Start/Magnetic Accessory Type Ballast Wattage 100 W Manufacturer Vossloh Schwabe Dimming? Non-Dimmable Frequency 50 Hz Height 42 mm Length 108 mm Type Control Gear Voltage 220-240 Volt Width 86 mm Control Gear Technology Discharge

Read more less

Vossloh Schwabe Electronic Ballast 2x 38w T8 Type ELXc 238.527 Ref.No 188137

Read more less

The Osram QTP-DL 2x55/220-240 is a non dimmable high frequency ballast to run 2 x 55w Long single turn PL-L compact fluorescent lamp. Product family benefits Long lamp life No adverse effect from frequent on/off switching Automatic restart after lamp replacement Perfect lamp start for applications with motion sensors VDE/VDE EMC certified system Very high energy efficiency due to cut-off technology Areas of application Emergency lighting systems acc. to EN 50172 / DIN VDE 0108-100 Open-plan offices, corridors and storage rooms Public buildings Suitable for luminaires of protection classes I and II Data sheet More downloads Technical Data Electrical data Input voltage AC 198…264 V Nominal voltage 220…240 V Mains frequency 50…60 Hz Input voltage DC 176…276 V Maximum output power 2 x 55 W Efficiency in full-load 95 % Operating frequency 40…50 kHz Max. ECG no. on circuit breaker 10 A (B) 8 Max. ECG no. on circuit breaker 16 A (B) 13 Inrush current 28 A Light technical data Starting time 1.0 s Dimensions & weight Length 360.0 mm Width 30.0 mm Height 21.0 mm Mounting hole spacing, length 350.0 mm Product weight 265.00 g Temperatures & operating conditions Ambient temperature range -20…+50 °C Permitted rel. humidity during operation 5…85 % Lifespan ECG lifetime 50000 h Additional product data Suitable for lamp power (2 lamps) 55 W Capabilities Suitable for fixtures with prot. class I / II End of lamp life safety shutdown EOL T.2 Intended for no-load operation No Max. cable length to lamp/LED module 2.0 m / 1.0 m Dimmable No Certificates & standards Approval marks – approval VDE / VDE-EMC / ENEC 10 / GOST / RCM EEI – Energy Label A2 BAT Standards Acc. to EN 61347-2-3/Acc. to EN 60929/Acc. to EN 55015:2006 + A1:2007/Acc. to EN 61000-3-2/Acc. to EN 61547 Type of protection IP20 Protection class III Logistical data Commodity code 850410809000 Environmental information Information according Art. 33 of EU Regulation (EC) 1907/2006 (REACh) Date of Declaration 14-04-2022 Primary Article Identifier 4008321390172 Candidate List Substance 1 Orange lead (lead tetroxide) CAS No. of substance 1 1314-41-6 Candidate List Substance 2 Lead CAS No. of substance 2 7439-92-1 Safe Use Instruction The identification of the Candidate List substance is sufficient to allow safe use of the article. Declaration No. in SCIP database 65971722-45e8-4623-b17a-f93e23c6b0bd

Read more less

1 x 58w T8 Magnetic Ballast

Read more less

15-20W Magnetic CFL Ballast

Read more less

The Philips HF-P 254/55 T5 HO/PLL is a fixed output high frequenct ballast for use with 2 x 54w flourescent lamps or 2 x 55w PL-L lamps. This ballast has a flicker free warm start, electrode heating cut off, Low energy consumption and automatic stop circuit (stop start). The Philips HF-P is often used in Department stores, Airports, Railway stations, Hotels and Hospitals. It is also suitable for emergency installations.   https://www.easy-controlgear.com/products/osram-qtp-optimal-2x54-58-4008321880253?_pos=1&_sid=c04cc9969&_ss=r

Read more less
