Constant current designIP66 ratedProtections: Short circuit/ Overload/ Over temp.Input Voltage: 100 – 240VACCooling by free air convectionLow cost, high reliabilityOutput Power: 4WCompact and light-weight plastic caseWorking Temperature: 0°C to +45°C3 year warrantyMore Information
Manufacturer
Ecopac Power
Output Wattage (W)
7
Dimmable (Type)
No
Dimensions
38x 30x 23.5
EMC Standards
EN55015, EN61000-3-2, EN61000-3-3, EN61547
Input Voltage
100~240VAC
Safety Standards
EN61347-1, EN61347-2-13
Output Voltage Options
Single
Working Temperature
-40~+85°C
PDF Datasheet
ECP4-ILP.pdf
Ecopac ELED-30-24DP2 DALI Dimmable, constant voltage LED driver.
Built in short circuit, overload, over current and over temperature protection together with a 3 year warranty make the ELED-30-24DP2 highly reliable.
• Constant voltage/ PWM Output (NFC regulation)• DALI & Push dimming function (0-100%)• AC input: 100-277VAC• Built-in active PFC function• Efficiency up to 83%• Protections: Short circuit/ Over load/Over temperature• Cooling by free air convection• IP20 design for indoor installation.• Suitable for intelligent LED lighting
More Information
Brand
Ecopac Power
Output Wattage (W)
30
Output Voltage
24V
IP Rating
IP20 Non Waterproof
Dimmable (Type)
DALI, Push Dimming
Dimensions
171.5 x 54 x 20 mm
EMC Standards
Compliance to EN55015, EN61000-3-2, EN61000-3-3 (≥60% load)
Input Voltage
100~277VAC
Safety Standards
EN61347-1, EN61347-2-13, EN62493, IP20 , UL8750 (US)
Output Voltage Options
Single
Working Temperature
-40~+60°C
PDF Datasheet
ELED-30-DP2_2022-04-14-094641.pdf
Constant Voltage Design 12V or 24V Output
Dimmable using leading edge & trailing edge Triac Dimmers
PWM Output
3 Years warrantyMore Information
Manufacturer
Ecopac Power
Output Wattage (W)
60
Dimmable (Type)
Triac Leading edge & Trailing edge
Dimensions
178x 61x 24
EMC Standards
Compliance to EN55015, EN61000-3-2,3 (>60% load)
Input Voltage
200-240VAC
Safety Standards
EN61347-1, EN61347-2-13
Working Temperature
-40~+70°C
PDF Datasheet
ELED-60P-T.pdf
Constant Voltage Design
0-10V Dimmable
Protections: Short circuit/ Over Voltage/ Overload
Other features:
Universal AC input/ Full range
IP66 design for indoor or outdoor installations
Built-in PFC function
Cooling by free air convection
Over 83% efficiency
3 years warrantyMore Information
Manufacturer
Ecopac Power
Output Wattage (W)
100
Output Voltage
12V
Dimmable (Type)
0-10V
Dimensions
230x 68.5x 44
EMC Standards
Compliance to EN55015, EN61000-3-2 (>50% load) Compliance to EN61000-4-2,3,4,5,6,11 EN61547 A light industry level
Input Voltage
100-265VAC
Safety Standards
EN61347-2-13, IP66
Output Voltage Options
Single
Working Temperature
-40~+60°C
PDF Datasheet
ELED-100 0~10V Series.pdf
Constant current designIP66 ratedProtections: Short circuit/ Overload/ Over temp.Input Voltage: 100 – 240VACCooling by free air convectionLow cost, high reliabilityOutput Power: 4WCompact and light-weight plastic caseWorking Temperature: 0°C to +45°C3 year warrantyMore Information Manufacturer Ecopac Power Output Wattage (W) 10 Output Current 350mA Dimmable (Type) No Output Voltage Range (V) 12 Max Dimensions 38x 30x 23.5 EMC Standards EN55015, EN61000-3-2, EN61000-3-3, EN61547 Input Voltage 100~240VAC Safety Standards EN61347-1, EN61347-2-13 Output Voltage Options Single Working Temperature -40~+85°C PDF Datasheet ECP4-ILP.pdf
Similar to : AU-LED0335CC
Obsolete please order either of the below depending on the Ma you are using
If between 250 /700Ma
https://www.easy-controlgear.com/products/eled-20p-c250-700t-constant-current-led-drivers-10-5-20-3w?_pos=8&_sid=8e6a3d564&_ss=r
If you are using less than 250Ma
https://www.easy-controlgear.com/products/eled-10p-c100-450t-series-constant-current-led-drivers-4-2-10w?_pos=1&_sid=daab3a194&_ss=r
The Ecpoac Power ELED-15-C150/700T features the ability to select the output current required between 150mA and 700mA via a set of dip switches. This LED driver is also dimmable using triac dimming. Ecopac LED drivers are high quality at affordable cost and come complete with a 3 year warranty. Constant current mode output Multiple current levels selectable by dip switch Protections: Short circuit/ Over load/ Over Current Other features: Full protection housing IP20 design for indoor installation Cooling by free air convection Dimming function : Triac dimmable 3 years warrantyMore Information Manufacturer Ecopac Power Output Wattage (W) 15 Output Current Selectable Dimmable (Type) Leading edge, Triac Output Voltage Range (V) 3-50V DC Output Adjustment 150-700mA Dimensions 140x 45x 28 (LxWxH) Mm EMC Standards Compliance to EN61000-4,2,3,4,5,6,11, EN61547, A light industry level ( surge 4KV ) Input Voltage 180-240VAC Safety Standards EN61347-1, EN61347-2-13 Output Voltage Options Single Working Temperature -40~+60°C PDF Datasheet ELED-15-CT.pdf
The Ecopac DALI-801-8A LED dimming inteface can be used in conjuction with non dimmable LED drivers to provide DALI dimming.
8A Maximum current
12-36VDC input voltage
1 DALI address input
1 Channel OutputMore Information
Output Voltage
12
Manufacturer
Ecopac Power
Output Wattage (W)
288
Dimmable (Type)
DALI
Dimensions
82x 33x 20
Input Voltage
12-36VDC
Working Temperature
-40~+85°C
PDF Datasheet
Dali-801-8A.pdf
ELED-40P-C300/1400T Series Features:
Features:
• Constant Current mode output with multiple levels selectable by dip switch• Dimming function: Triac/phase cut dimming• Work with leading or trailing edge Triac dimmer• (ON key: leading edge; 1 key: trailing edge)• AC input: 200-240VAC• Built-in active PFC function• Efficiency up to 80%• IP20 design for indoor installation• Full protection plastic housing easy installation• Protections: Short circuit/ Over load• Cooling by free air convection• Suitable for LED lighting and moving sign applications• Strong compatibility, flicker-free dimming
https://www.ecopacpower.co.uk/assets/pdf/ELED-40P-C300-1400T.pdf
Built-in active PFC function
Dali Dimmable
Protections: Short circuit/ Over Current/ Over Loading
Other features:
IP20 Design for Indoor Installations
Dimming function : Built-in Dali interface push dimming
Suitable for intelligent LED lighting
Suitable for dry locations
3 years warrantyMore Information
Manufacturer
Ecopac Power
Output Voltage
24
Dimensions
80x 36x 23
EMC Standards
Compliance to EN55015, EN61000-3-2-3 (>50% load) Compliance to EN61000-4-2,3,4,5,6,11(surge 4KV)
Input Voltage
100-265VAC
Safety Standards
EN61347-1, EN61347-2-13
Output Voltage Options
Single
Working Temperature
-40~+60°C
PDF Datasheet
ELED-10-D UP.pdf
Constant voltage Triac/ Mains dimming
Suitable for leading/ trailing edge
Protections: Short circuit/ Over voltage
Other features:
Built-in active PFC funtion (PF>0.95)
Cooling by free air convection
IP66 Design
Fully isolated, delivering up to 80W of powerMore Information
Manufacturer
Ecopac Power
Output Wattage (W)
80
Dimmable (Type)
Triac Leading edge & Trailing edge
Dimensions
200x 68x 45
EMC Standards
Compliance to EN55015, EN61000-3-2 (?50% load), EN55015, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547, light industry level
Input Voltage
175~265VAC
Safety Standards
EN-60950-1
Output Voltage Options
Single
Working Temperature
-40°C ~ +60°C
PDF Datasheet
ELED-80-T.pdf
