Please NOTE you need to select the Ma rating you wish to have it programmed to .
SOLOdrive 240/A delivers 20W and is DALI-2 certified. As all SOLOdrives, the 240/A smoothly dims all the way down to dark.
The 20W /A independent LED driver with cable retention is perfect for downlight applications in Europe where the LED driver needs to fit through a 50mm diameter hole in the ceiling into a plenum with a 110mm height between functional and decorative ceiling.
Features
Hybrid HydraDrive: provides the smoothest flicker-free high-performance dimming to zero for every fixture
LEDcode2: connects to integrated digital accessories, supports location-based IoT applications and enables wired and wireless lighting control through LEDcode peripheral devices
NTC interface for robust thermal management
Benefits
Increase performance and capability of any LED fixture
Reduce inventory and decrease lead times with configurable drivers
Short lead times, designed to meet the most aggressive timelines
Trusted brand with proven track record of performance and reliability
Certifications SL0240A3
CE
EN 61347-1/-2-13, EN 62384, EN 55015, EN 55022, EN 61000-3-2, EN 61547
IEC 62386-101 Ed. 2.0, IEC 62386-102 Ed. 2.0, IEC 62386-207 Ed. 1
ENEC by DEKRA
EL
RCM
LINEARdrive 180D is a constant voltage LED driver. It features four LED outputs that can be controlled individually via DMX.
You can configure the driver over its intuitive, 3-button user interface with display: it lets you configure the number of channels, DMX settings for networked mode and show, colour and dim values for standalone operation.
The driver features wire restraints which make it perfectly suited for independent installations.
Features
HydraDrive: provides the smoothest colour fades and dimming to dark
User interface for driver configuration
Benefits
Dynamic response can be tuned to fit any content - from exceptionally smooth fades in architecture to fast-paced video in entertainment
Configurable on-the-fly
Input Characteristics
Nominal input voltage DC: 12 - 28V Maximum input current: 6A, irrespective of PSU voltage
Output Characteristics
LED output load: RGBW @ 12V: 1.5A RGB @ 12V: 2A RGBW @ 24V: 1.5A RGB @ 24V: 2A Maximum LED output power: 180W Number of LED outputs: 4 (UL Class 2) LED output voltage: 12 - 24V
Downloads
Datasheet LIN180D3Specification submittal sheetWiring diagramQuick Start Guide
Please allow 5/7 days delivery
LINEARdrive gives you all the control you need for your low-voltage LED application. This constant voltage LED driver is DALI DT8compatible and enables you to create the perfect shade of white or show sequence without an external controller. Symbiosis ensuresthe LED driver works seamlessly together with LED modules, controls and intelligent luminaire elements.
LINEARdrive 210D is a constant voltage LED driver. It features two LED outputs that are controlled via DALI. Both LED outputs are controlled over the same ballast, giving them the exact same behaviour.
The driver features wire restraints which make it perfectly suited for independent installations.
Features
HydraDrive: provides the smoothest colour fades and dimming to dark
Auxiliary power output
Benefits
Exceptionally smooth colour fades
Input Characteristics
Nominal input voltage DC: 12 - 28V Maximum input current: 8A, irrespective of PSU voltage
Output Characteristics
LED output load: 8A maximum, irrespective of whether using one or both LED outputs Maximum LED output power: 200W Number of LED outputs: 2 LED output voltage: 12 - 28V Auxiliary output voltage: equal to input voltage Auxiliary output current: 180mA @ 12V, 90mA @ 24V Maximum auxiliary output power: 2W
This SOLOdrive product will be configured to your required current at any interval between 150mA and 1050mA. Please state your required current in the box above. If you do not require this extra service & wish to purchase this product at the pre-configured current of 350mA
SOLOdrive 241/A2 delivers 20W and is 0-10V compatible. As all SOLOdrives, the 241/A2 smoothly dims all the way down to dark.
The 20W /A independent LED driver with cable retention is perfect for downlight applications in Europe where the LED driver needs to fit through a 50mm diameter hole in the ceiling into a plenum with a 110mm height between functional and decorative ceiling.
Features
Hybrid HydraDrive: provides the smoothest flicker-free high-performance dimming to zero for every fixture
LEDcode technology: configurable design to work with most constant current LED modules and arrays, while providing a connection point to integrated peripheral controls
NTC interface for robust thermal management
Benefits
Increase performance and capability of any LED fixture
Reduce inventory and decrease lead times with configurable drivers
Short lead times, designed to meet the most aggressive timelines
Trusted brand with proven track record of performance and reliability
Input Characteristics
Nominal input voltage range AC: 220 - 240V (ENEC) Absolute input voltage range AC: 198 - 264V Nominal input voltage range DC: 176 - 250V Maximum input current: 0.15A @ 230V / 50Hz Input frequency range: 50 - 60Hz
Output Characteristics
Maximum LED output power: 20W Number of LED outputs: 1 Programmable LED output current range: 150 - 1050mA LED output type: Programmable in 1mA increments within specified current rangeLED output current tolerance: +/- 5% at programmed LED output current LED output voltage range: 2 - 40V
Downloads
Datasheet SL0241A2Specification submittal sheet
