Constant Voltage Fully encapsulated with IP67 level Protections: Short circuit/ Overload/ Over voltage Other features: Universal AC input / Full Range Class 2 power unit Isolation class II, no F.G. Withstand 300VAC surge input for 5 seconds Cooling by free air convection Pass LPS 100% full load burn-in test Low cost, High reliability 2 years warrantyMore Information Manufacturer Mean Well Output Wattage (W) 20 Output Voltage 12V Dimmable (Type) No DC Output Adjustment N/A Dimensions 118 x 35 x 26 EMC Standards EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11 Input Voltage 90~264VAC Safety Standards UL1310, UL879 approved; Design refer to TUV EN60950-1, EN61347-2-13 Output Voltage Options Single Working Temperature -30°C~+70°C
Constant Voltage
Fully encapsulated with IP67 level
Protections: Short circuit/ Overload/ Over voltage
Other features:
Universal AC input / Full Range
Class 2 power unit
Isolation class II, no F.G.
Withstand 300VAC surge input for 5 seconds
Cooling by free air convection
Pass LPS
100% full load burn-in test
Low cost, High reliability
2 years warranty
Constant Voltage
Fully encapsulated with IP67 level
Protections: Short circuit/ Overload/ Over voltage
Other features:
Universal AC input / Full Range
Class 2 power unit
Isolation class II, no F.G.
Withstand 300VAC surge input for 5 seconds
Cooling by free air convection
Pass LPS
100% full load burn-in test
Low cost, High reliability
2 years warranty
Constant Voltage Fully encapsulated with IP67 level Protections: Short circuit/ Overload/ Over voltage Other features: Universal AC input / Full Range Class 2 power unit Isolation class II, no F.G. Withstand 300VAC surge input for 5 seconds Cooling by free air convection Pass LPS 100% full load burn-in test Low cost, High reliability 2 years warrantyMore Information: Manufacturer: Mean Well Output Wattage (W) 60 Output Voltage 24V Dimmable (Type) No DC Output Adjustment N/A Dimensions 162.5 x 42.5 x 32 EMC Standards EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11 Input Voltage 90~264VAC Safety Standards UL1310, UL879 approved; Design refer to TUV EN60950-1, EN61347-2-13 Output Voltage Options Single Working Temperature -30°C~+70°C
LS-30 LI Series Features:
Constant Voltage design
Input Voltage 220-240VAC
Other features:
Protections: short circuit/over load/over voltage
IP20 Ingress protection
Flicker Free
Power Factor b %0.9
Efficiency b %87%
Class II, SELV
3 years warranty
Wattage
30
30
Input Voltage
220-240VAC
220-240VAC
Output Current
2.5A
1.25A
Output Voltage
12V
24V
Output Voltage Options
Single
Single
Dimensions
142 x 45 x 30
142 x 45 x 30
Working Temperature
-10 - +45°C
Safety Standards
EN 61347-1; EN61347-2-13
EMC Standards
EN55015; EN61000-3-2 Class C; EN61000-3-3, EN 61547;EN 61000-4-2, Performance Criteria B; EN 61000-4-5, 1000V Performance Criteria
