The Osram QT-FIT5 1x54w is a non dimmable high frequency ballast to run: 1 x 54w T5 Fluorescent Tube These ballasts have an average lifetime of 50,000 hours, an EEI class of A2.
Product family benefits
Long lamp life
No adverse effect from frequent on/off switching
Automatic restart after lamp replacement
Perfect lamp start for applications with motion sensors
VDE/VDE EMC certified system
Very high energy efficiency due to cut-off technology
Areas of application
Open-plan offices, corridors and storage rooms
Public buildings
Strip lighting
Suitable for emergency lighting (DC operation)
Suitable for luminaires of protection class I
Modernization of existing systems
Data Sheet
Product data sheet
The Osram QT-FIT5 3/4x14 is a non dimmable high frequency ballast to run: 3/4 x 14w T5 Fluorescent Tube These ballasts have an average lifetime of 50,000 hours, an EEI class of A2.
Product family benefits
Long lamp life
No adverse effect from frequent on/off switching
Automatic restart after lamp replacement
Perfect lamp start for applications with motion sensors
VDE/VDE EMC certified system
Very high energy efficiency due to cut-off technology
Areas of application
Open-plan offices, corridors and storage rooms
Public buildings
Strip lighting
Suitable for emergency lighting (DC operation)
Suitable for luminaires of protection class I
Modernization of existing systems
Data Sheet
Product data sheet
Product family benefits
Long lamp life
No adverse effect from frequent on/off switching
Automatic restart after lamp replacement
Perfect lamp start for applications with motion sensors
VDE/VDE EMC certified system
Very high energy efficiency due to cut-off technology
Areas of application
Open-plan offices, corridors and storage rooms
Public buildings
Strip lighting
Suitable for emergency lighting (DC operation)
Suitable for luminaires of protection class I
Technical Data
Electrical data
Input voltage AC
198…264 V
Nominal voltage
220…240 V
Mains frequency
50…60 Hz
Input voltage DC
185…264 V
Maximum output power
2 x 70 W
Efficiency in full-load
91 %
Operating frequency
40…50 kHz
Max. ECG no. on circuit breaker 10 A (B)
8
Max. ECG no. on circuit breaker 16 A (B)
13
Inrush current
15 A
Light technical data
Starting time
2.0 s
Dimensions & weight
Length
360.0 mm
Width
30.0 mm
Height
28.0 mm
Mounting hole spacing, length
350.0 mm
Product weight
264.00 g
Cable cross-section, output side
0.5…1.5 mm²
Cable cross-section, input side
0.5…1.5 mm²
Temperatures & operating conditions
Ambient temperature range
-15…+50 °C
Permitted rel. humidity during operation
5…85 %
Lifespan
ECG lifetime
50000 h
Additional product data
Suitable for lamp power (2 lamps)
58…70 W
Capabilities
End of lamp life safety shutdown
EOL T.2
Suitable for fixtures with prot. class
I
Max. cable length to lamp/LED module
2.0 m / 1.0 m
Intended for no-load operation
No
Dimmable
No
Certificates & standards
Approval marks – approval
VDE / VDE-EMC / ENEC 10 / CE
EEI – Energy Label
A2
Standards
Acc. to EN 61347-2-3/Acc. to EN 60929/Acc. to EN 55015:2006 + A1:2007/Acc. to EN 61000-3-2/Acc. to EN 61547
Type of protection
IP20
Protection class
I
Logistical data
Commodity code
850410809000
Environmental information
Information according Art. 33 of EU Regulation (EC) 1907/2006 (REACh)
Date of Declaration
13-02-2022
Primary Article Identifier
4052899151932
Candidate List Substance 1
Lead
CAS No. of substance 1
7439-92-1
Safe Use Instruction
The identification of the Candidate List substance is sufficient to allow safe use of the article.
Declaration No. in SCIP database
59247456-2dea-40a9-b909-81746510b756
Packaging information
EAN
Unit
Piece
Dimension l x w x h
Weight
Volume
4052899151932
UNV
1
360mm x 30mm x 28mm
264.00g
0.30dm³
4052899151949
VS
20
383mm x 159mm x 132mm
5442.00g
8.04dm³
The Osram QTP8 1x18 is a non dimmable high frequency ballast to run: 3 or 4 x 18w 2ft T8 Fluorescent Tube These ballasts have an average lifetime of 50,000 hours, an EEI class of A2. They are suitable for applications with motion detectors and emergency lighting applications.
The Osram QTI 1x14/21/24/39/230-240 is a high frequency ballast to run: 1x 14w,21w,24w & 39w T5 lamps.
These ballasts have an average lifetime of 100,000 hours They offer flicker free light, have an automatic safety shutdown at lamp failure, automatic restart after lamp replacement and are suitable for emergency lighting.
Product family benefits
Long lamp life
No adverse effect from frequent on/off switching
Automatic restart after lamp replacement
Perfect lamp start for applications with motion sensors
VDE/VDE EMC certified system
Very high energy efficiency due to cut-off technology
Areas of application
Emergency lighting systems acc. to EN 50172 / DIN VDE 0108-100
Industry
Open-plan offices, corridors and storage rooms
Public buildings
Sports halls and factories
Strip lighting
Suitable for emergency lighting (DC operation)
Modernization of existing systems
Suitable for luminaires of protection classes I and II
The Osram QTi 1x28/54/220-240 DIM is a 1-10v intelligent dimmable ballast to run 1 x 28w or 54w T5 Tubes. These ballasts have an average life of 100,000 hours, offer flicker free light, have an automatic safety shutdown at lamp failure, automatic restart after lamp replacement and are suitable for emergency lighting.
Product benefits
Same luminous flux with direct and alternating current
Perfect lamp start for applications with motion sensors
Dimming of amalgam lamps without flickering or reduced lifespan
Very high efficiency thanks to cut-off technology
Automatic restart after lamp replacement
ECGs comply with MINERGIE standard due to very low standby consumption
Configurable emergency power characteristics
Osram QTi 2X14/24 DIM 4050300870946
Product family features
– Control via 1…10 V interface
-Supply voltage: 220…240 V
-Line frequency: 0 Hz | 50 Hz | 60 Hz- Line voltage: 198…264 V
– Dimming range: 1…100 % luminous flux
– Lamp start: within 0.6 s
– Lifetime: > 100,000 h (for T = 65 °C at Tc)
– Automatic shutdown of defective lamps and at end of life(EoL T.2)
– Energy Efficiency Index EEI: A1 BAT
– Overtemperature protection: Thermal management at hightc temperatures
– Safety: to EN 61347-2-3
– Lamp operation: to EN 60929
– RI suppression: to EN 55015:2006+A1:2007+A2:2009/CISPR15
– Line harmonics according to EN 61000-3-2
– Immunity according to EN 61547
Product family benefits
_ Same luminous flux with direct and alternating current_ Perfect lamp start for applications with motion sensors_ Dimming of amalgam lamps without flickering or reduced lifespan_ Very high efficiency thanks to cut-off technology_ Automatic restart after lamp replacement_ ECGs comply with MINERGIE standard due to very low standby consumption _ Configurable emergency power characteristics
Areas of application
_ Suitable for emergency installations_ Industry_ Open-plan offices, corridors and storage rooms _ Public buildings_ Suitable for luminaires of protection class I
Product Data Sheet
OSQN214D.pdf
The Osram QTi 2x21/39/220-240 DIM is a 1-10v intelligent dimmable ballast to run 2 x 21w or 39w T5 Tubes. These ballasts have an average life of 100,000 hours, offer flicker free light, have an automatic safety shutdown at lamp failure, automatic restart after lamp replacement and are suitable for emergency lighting.
The Osram QTi 4x18/220-240 DIM is a 1-10v intelligent dimmable ballast to run 4 x 18w T8 Tubes. These ballasts have an average life of 100,000 hours, offer flicker free light, have an automatic safety shutdown at lamp failure, automatic restart after lamp replacement and are suitable for emergency lighting.
Osram QTi DALI 1X21/39 DIM 4050300870366
Product family features
Corridor function for direct connection of ECG to common motion sensor
Corridor function with pre-programmed light program
Touch DIM function for free parameterization of light value and turn on time
Fit for SMART GRID for feedback of consumed mains power and lamp operating hours
Fit for emergency function for automatic detection of emergency lighting by ECG
Very low standby power consumption: < 0.5 W
Lifetime: > 100,000 h (for T = 65 °C at Tc)
Very high number of switching cycles: up to 300,000
Dimming range: 1…100 % (3…100 % with compact fluorescent lamp)
POWER2LAMP function for optimal matching of ECG power to lamp during lamp lifetime
Line frequency: 0 Hz, 50…60 Hz, rectified AC
Product family benefits
– System+ Guarantee available– Easy integration in luminaire thanks to same dimensions like DALI GI ECG _ Touch DIM function for easy and inexpensive dimming of several ECGs– Same luminous flux with direct and alternating current– Dimming of amalgam lamps without flickering or reduced lifespan– Automatic restart after lamp replacement
DALI product features
– Control via the DALI interface– Compliance with the DALI Version-1 and IEC 60929– Control input protected against overvoltage and polarity reversal (OSRAM ECG)
Touch DIM and Touch DIM Sensor function– Manual dimming without controller and with standard switches
-Including memory function (double click) and soft start
Product Data Sheet
OSQNDA121.pdf
System+ Guarantee available
Easy integration in luminaire thanks to same dimensions like DALI GI ECG
TouchDIM function for easy and inexpensive dimming of several ECGs
Same luminous flux with direct and alternating current
Dimming of amalgam lamps without flickering or reduced lifespan
Automatic restart after lamp replacement
The Osram QTi DALI 1x58/220-240 DIM is a digital dimmable ballast to run 1 x 58w T8 Tubes. These ballasts have an average life of 100,000 hours, offer flicker free light, have an automatic safety shutdown at lamp failure, automatic restart after lamp replacement and are suitable for emergency lighting.
