HF-Performer II for PL-T/C/R/L/TL5C lamps
HF-Performer II for PL-T/C/R/L/TL5C lamps HF-P 1 22-42 PL-T/C/L/TL5C EII 220-240V HF-Performer EII PL-T/C/R/T5c is a sustainable, slim and high-frequency electronic ballast for a wide range of CFL- ni applications.
It is ideal for applications where high energy efficiency is required. The HF-Performer EII range has a robust design, meets all relevant international safety and performance standards and is energy-efficient (CELMA EEI A2).
Lamp type PL-T/C/L/TL5C Number of lamps 1 piece/unit Automatic restart Yes Operating and Electrical Input Voltage 220 to 240 V Input frequency 50 to 60 Hz Operating frequency (max.) - kHz
View Datasheet
General Information
Application Code
III
Lamp Type
PL-T/C
Number of Lamps
2 piece/unit
Number of Products on MCB (16A Type B) (Nom)
28
Automatic Restart
Yes
Operating and Electrical
Input Voltage
220 to 240 V
Input Frequency
50 to 60 Hz
Operating Frequency (Max)
- kHz
Operating Frequency (Min)
42 kHz
Operating Frequency (Nom)
45 kHz
Ignition Method
Warm Start
Crestfactor (Max)
1.7
Power Factor 100% Load (Nom)
0.95
Ignition Time (Max)
0.40 s
Mains Voltage Performance (AC)
-8%-+6%
Mains Voltage Safety (AC)
-10%-+10%
Earth Leakage Current (Nom)
0.5 mA
Inrush Current Width
0.250 ms
Constant Wattage Deviation
-2%/+2%
Ballast Factor (Nom)
1
Power Losses (Nom)
0.68-2.21 W
Inrush Current Peak (Max)
18 A
Efficiency at full load [%]
87.97 %
The Osram QTP-OPTIMAL 2x18-40 is a Multiwatt non dimmable high frequency ballast to run 2 x 18w, 24w, 36w, 40w PL-L, 18w & 24w DULUX F, 15w & 18w 30W T8 tubes and 24w & 39w T5 lamps.
Product family benefits
Long lamp life
No adverse effect from frequent on/off switching
Automatic restart after lamp replacement
Perfect lamp start for applications with motion sensors
VDE/VDE EMC certified system
Very high energy efficiency due to cut-off technology
Areas of application
Emergency lighting systems acc. to EN 50172 / DIN VDE 0108-100
Industry
Open-plan offices, corridors and storage rooms
Public buildings
Sports halls and factories
Strip lighting
Suitable for emergency lighting (DC operation)
Modernization of existing systems
Suitable for luminaires of protection classes I and II
Data Sheet
Product Data Sheet
Stock clearance, buy fast whilst stocks last
The Osram QTP-DL 2x36-40/220-240 is a non dimmable high frequency ballast to run 2 x 36 or 40w Long single turn PL-L compact fluorescent lamp.
Digital Dimming Ballast to run 1 X 28/54w T5 tubes - PCA 1x28/54 T5 ECO - 22185099
Product description _ Processor-controlled ballast with yII inside _ Highest possible energy class CELMA EEI = A1 BAT 1 _ Noise-free precise control via DALI or DSI signal, switchDIM or corridorFUNCTION _ Nominal lifetime up to 100,000 h (at ta 50 °C with a failure rate ≤ 0.2 % per 1,000 h) _ Multilamp management _ OEM-specific reserved memory areas _ 5 years guarantee Interfaces _ DALI _ DSI _ switchDIM (with memory function + selectable dimming rate) _ corridorFUNCTION (3 preprogrammed profiles) _ Integrated SMART interface for function with SMART Sensor 5D 19f and corridorFUNCTION plugs _ SMART interface for SMART plug cF – for setting the corridorFUNCTION profiles _ SMART interface for SMART sensor with daylight control Functions _ Intelligent Temperature Guard (overtemperature protection) _ Intelligent Voltage Guard (overvoltage indication and undervoltage shutdown) _ Optimum filament heating in any dimmer setting _ Disconnection of filament heating from a dimming level of approx. 90 % for maximum energy efficiency (SMART-Heating concept) _ corridorFUNCTION with ambient light control _ Automatically triggered emergency lighting value in DC mode, 15 % _ For emergency lighting systems as per EN 50172 _ Automatic start after replacement of defective lamp
Product Features
Flat, lightweight high-frequency electronic regulating ballast, using 1-10V protocol for TL5 fluorescent lamps
Features
Programmed start: flicker-free ignition < 0.5 seconds and striation-free operation, no stroboscopic effects. Preheating the lamp electrodes enables the lamps to be switched on and off without reducing life
Smart power ensures constant light, independent of mains fluctuations
Up to 60% reduction in energy consumption by using automatic lighting control systems
Stop circuit is activated within 5 seconds in the event of lamp failure (safety stop), and ballast resets automatically after lamp replacement
Application
1-10V installations with daylight linking and/or movement detection (for energy savings)
1-10V installations with remote control systems (combining energy savings with comfort)
Installations with emergency back-up, according to IEC 60598-2-22
