Product description LED Constant current LED Driver for luminaire installation New version DC operating with EL marking For luminaires of protection class I and protection class II Temperature protection as per EN 61347-2-13 C5e Output current adjustable between 350 – 500 mA Max. output power 69 W Up to 91 % efficiency Nominal lifetime up to 100,000 h 5 years guarantee Housing properties Low profile metal casing with white cover Type of protection IP20 Interfaces Terminal blocks: 45° push terminals Functions Overload protection Short-circuit protection No-load protection Burst protection voltage 1 kV Surge protection voltage 1 kV (L to N) Surge protection voltage 2 kV (L/N to earth) Typical applications For linear/area lighting in office applications

Read more less

  ELED-600-DP2 series Features: Description:600W DALI 2 & Push Dimmable LED DriverFeatures:Constant voltage/ PWM OutputDALI2Flicker free dimmingBuilt-in active PFC functionEfficiency up to 93%Protections: Short circuit/ Over load/ Over voltageCooling by free air convectionIP67 design for indoor and outdoor installationSuitable for intelligent LED lighting Ecopac Power offers from stock the ELED-600-24DP2, a 600 Watt 24 volt constant voltage DALI2 and Push Dim LED Driver designed to provide a smooth and integrated solution for LED lighting systems. With a built-in DALI interface, this innovative 600 watt LED Driver offers unmatched efficiency and control for various lighting applications With DALI2 and Push Dim technology, the ELED-600-24DP2 allows users to easily adjust and control the brightness levels of their lighting system. The DALI2 protocol provides a reliable and standardized interface for controlling lighting systems, while the Push Dim feature allows users to dim their lights with a simple push button. The ELED-600-24DP2 is rated for a maximum output of 600 watts, making it ideal for use in a variety of lighting applications, including commercial and residential settings. With advanced protection features including over-voltage protection, over-current protection, and short circuit protection to ensure safe and reliable operation. The ELED-600-24DP2 reflects Ecopac Power's commitment to providing high-quality, efficient and reliable lighting solutions to customers. With high efficiency and designed to deliver maximum power while minimizing energy consumption, helping to reduce operating costs and environmental impact.

Read more less

Specifications  929002101206 General information Protection class IEC Safety class I/II Operating and electrical Output Current Ripple (Max) 4 % Output Current (Max) 1050 mA Open Circuit Voltage (DC) (Max) 60 V Output Power (Max) 36 W Output Power (Min) 11 W Output Current (Min) 300 mA Output Voltage (Max) 54 V Output Voltage (Min) 24 V System characteristics Central DC Operation Yes YellowDot ready No Temperature T-Case Lifetime (Max) 80 °C T-Case Maximum (Max) 80 °C Controls and dimming Dimmable No Mechanical and housing Product Length 97 mm Housing Mini 97x43x30 2p2p Housing Dimensions 97.2 x 43 x 30 Overall length 97.2 mm Overall width 43 mm Overall height 30 mm Approval and application IP Classification IP20  [ Finger-protected] Isolation Classification Class I and Class II Approval Marks CE marking CB Certificate ENEC certificate CCC certificate RCM compliance Output Current Set Options NFC Product data Full product code 871869964976000 Order product name Xitanium 36W/m 0.3-1.05A 54V 230V EAN/UPC - Product 8718699649760 Order code 929001486006 Numerator - Quantity Per Pack 1 Numerator - Packs per outer box 20 Material Nr. (12NC) 929001486006 Net Weight (Piece) 0.100 kg

Read more less

ELED-100-DP2 Series Features: Features: • Constant voltage/ PWM Output (NFC regulation)• DALI & Push dimming function• AC input: 200-240VAC• Built-in active PFC function• Efficiency up to 89%• Protections: Short circuit/ Over load/Over temperature• Cooling by free air convection• IP66 design for indoor and outdoor installation.• Suitable for intelligent LED lighting   Suitable replacement for  the Ansell  ADDIM100/24V/DD ELED-100-12DP2 ELED-100-24DP2 Wattage 100 100 Input Voltage 100~277VAC 100~277VAC Output Current 8.34 4.17 Output Voltage 12 24 Dimensions 231x 78 x 25.1 mm 231x 78 x 25.1 mm Working Temperature -40~60°C Safety Standards EN61347-1, EN61347-2-13, EN62493, IP66 EMC Standards Compliance to EN55015, EN61000-3-2, EN61000-3-3 (≥60% load)

Read more less

Depth31.5mmLead FreeLead FreeLength179mmNominal Output Voltage48VNumber of Channels1Output Current350mAOutput Power33WOutput Voltage48VTerminationTerminal BlockWidth31mm https://datasheet.ciiva.com/5802/1444537-5802780.pdf

Read more less

The Ecopac ELED-75-12D DALI Dimmable LED Driver is 75W 12VDC output.  Constant Voltage  / PWM Output Design Dali & Push Dimmable Protections: Short circuit/ Over Voltage/ Over Temperature Other features: Dimming range from 0.1% to 100% Input Range 200-265VAC Output 12VDC Built-in PFC function IP20design for indoor or outdoor installations 87% efficiency 3 years warrantyMore Information Manufacturer Ecopac Power Output Wattage (W) 75 Output Voltage 12V Dimmable (Type) DALI, Push Dimming DC Output Adjustment No Dimensions 355 x 215 x 215 mm EMC Standards Compliance to EN55015, EN61000-3-2, EN61000-3-3 (?60% load), EN61000-4-2,3,4,5,6,11, EN61547 Input Voltage 100-265VAC Safety Standards EN61347-1, EN61347-2-13, EN62493, IP20 Output Voltage Options Single Working Temperature -40 ~ +60°C PDF Datasheet ELED-75-D.pdf

Read more less

this product is not currently available , we would suggest an alternative please see below    https://www.easy-controlgear.com/products/mackwell-led-driver-dali-dimmable-33w-700ma-48v?_pos=2&_sid=78b811065&_ss=r Product Details Harvard CoolLED LED Driver provide a high-performance solution for powering high-brightness LEDs from a mains supply. It has an ability to control individual LED luminaries and simultaneous control of all or specified groups. High Efficiency and Long-Life design ensure cool operation and long life with extra benefit of a very low off power. Isolated DALI interface. Constant current output. Self-resetting thermal trip. Double insulated, electrical efficiency class II. Up to 88% efficiency. LED string fault reporting. Isolated DALI interface. Lamp fault reporting checks on LED string volts. · Isolated DALI interface · Constant current output · Self resetting thermal trip · LED string fault reporting · Lamp fault reporting checks on LED string volts Specifications Technical data Information Brand Harvard Power Systems Commodity 8504409090 Item number CL700D2-240-C Warranty pack 60 Months Bring-In Series CL RoHS Compliant Description AC-DC 33W LED driver Constant Current mode (CC); Max. output 48Vdc at 0.7A; IP20; Dimming with DALI; Remote control Packing Quantity 40 Application LED EN 61347 Net weight (gram) 130 Technology AC/DC Constant Current C.C. Format Box Type - Enclosed Output Power (W) 33 Output Voltage (V) 48 Output Current (A) 0.7 Input Voltage (V) 220 - 240 IP Rating IP20 Width (mm) 32 Height (mm) 32 Depth (mm) 180 Control Signals Remote Sense Dimming Technology DALI

Read more less

Driver LC 35W 800mA fixC SR SNC2 essence series Product description Independent driver with strain-relief housing For luminaires with M and MM as per EN 60598, VDE 0710 and VDE 0711 Temperature protection as per EN 61347-2-13 C5e Output current 800 mA Max. output power 35 W Nominal lifetime up to 50,000 h 5 years guarantee Housing properties Casing: polycarbonate, white Type of protection IP20 Push-in terminals 2 separate strain relief parts for input and output cables with highly robust clamps Functions Overload protection Short-circuit protection No-load protection No output current overshoot at mains on/off Burst protection voltage 1 kV Surge protection voltage 1 kV (L to N) Surge protection voltage 2 kV (L/N to earth) Typical applications For spot light and downlight in retail and hospitality applications For panel light and area light in office and education application

Read more less

Constant voltage design Built-in active PFC function Protections: Short circuit/ Overload/ Over temp. Input Voltage: 200 – 240VAC Cooling by free air convection Output Power: 75W Compact and light-weight plastic case Working Temperature: -20C to +45C 3 year warrantyMore Information Manufacturer Ecopac Power Output Wattage (W) 75 Output Voltage 24V Dimmable (Type) No DC Output Adjustment N/a Dimensions 200x 63x 30 EMC Standards EN55015, EN61000-3-2, EN61000-3-3, EN61547 Input Voltage 200~240VAC Safety Standards EN61347-1, EN61347-2-13 Working Temperature -40~+85°C PDF Datasheet ECP75_Series_3.pdf   Similar to the  SLT75-24VL-2

Read more less

Built-in active PFC function, PF>0.9 for 75% of load or higherBuilt-in constant current limiting circuit (C.V + C.C mode)Protections: Short circuit / Over current / Over voltage / Over temperatureOther features:Universal AC input (up to 295 VAC) / Full rangeIP65 design for indoor or outdoor installationsCooling by free air convectionSuitable for LED lighting, street lighting and moving sign applicationsMeet 4KV surge immunity level (IEC 61000-4-5)Output voltage and C.C level can be adjusted through internal potentiometer3 years warranty More Information Manufacturer Mean Well Output Wattage (W) 150 Output Voltage 24V Dimmable (Type) No DC Output Adjustment A type can be adjusted by internal potentiometer Dimensions 222 x 68 x 39 EMC Standards EN55015, EN55022 class B, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547 Input Voltage 90~295VAC, 127~417VDC Safety Standards UL60950-1 , UL1012, UL8750, TUV EN60950-1, EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13 Output Voltage Options Single Working Temperature -30~+70°C (refer to output derating curve) PDF Datasheet CLG-150-spec.pdf

Read more less

Constant Voltage Fully encapsulated with IP67 level Protections: Short circuit/ Overload/ Over voltage Fully isolated plastic case Cooling by free air convection 100% full load burn-in test Low cost, High reliability 2 years warranty Other features: Universal AC input / Full Range Class II power unit, no F.G. More Information: Manufacturer: Mean Well Output Wattage (W): 150 Output Voltage: 24V Dimmable (Type): No Dimensions: 190 x 61 x 37 EMC Standards EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11 Safety Standards Design refer to TUV EN60950-1, EN61347-2-13 Output Voltage Options: Single Working Temperature -30°C~+70°C

Read more less

Driver LCA 150W 24V one4all SC PRE premium series 24 V – dimmable (IP20) With strain-relief Product description NEW: lumDATA (Luminaire data, Energy reporting and Diagnostics & Maintenance) Dimmable 24 V constant voltage LED driver for flexible constant voltage strips Can bei either used built-in or independent with clip-on strain-relief (see data sheet chapter: 1. Standards) One4all interface and ready2mains enable different dimming options Dimming range 1 to 100 % No additional external dimmer is needed Suitable for emergency escape lighting systems acc. to EN 50172 Nominal lifetime up to 50,000 h 5 years guarantee Typical applications Cove lighting, facade accent lighting, ceiling integration Technical details 24 V, 150 W Small design (325 x 43 x 30 mm) with stretched-compact strain relief Small cross section Push terminals for simple wiring Output terminals (+/–) equipped twice for more flexibility in the application Interfaces one4all (DALI DT 6, DSI, switchDIM, corridorFUNCTION) ready2mains (configuration and dimming via mains) Terminal blocks: 45° push terminals System solution Tridonic LLE-FLEX ADV 600, 1,200, 1,800 lm/m Tridonic LLE-FLEX EXC 600, 1,200, 1,800, 2,500 lm/m In connection with Flex accessories wire to PCB plug The functioning of third party light sources at a low dim level cannot be guaranteed and is not recommended
