Product description• Ideal for linear and panel lights• Luminous flux range 330 up to 1,840 lm• LED system solution with outstanding system efficacy up to145 lm/W, consisting of linear LED modules and dimmableLED Driver LCA 50W 100–400mA lp PRE• Efficacy of the module up to 172 lm/W• High colour rendering index CRI > 80• Small colour tolerance MacAdam 33• Small luminous flux tolerances• Colour temperatures 3,000 K, 4,000 K and 5,000 K• Perfectly uniform light, even if several LED modules are usedtogether in a line• Push terminals for quick and simple wiring of LED module toLED module• Simple installation (e.g. screws)• Long life-time: 50,000 hours• 5-year guarantee

Read more less

Product description_ Ideal for linear and panel lights_ 2 terminals for serial wiring_ Perfectly uniform light, even if several LED modules are usedtogether in a line_ Push terminals for quick and simple wiring of LED module to LEDmodule_ Option backside terminal_ Broad portfolio from extruded lenses and covers available_ HE ... High Efficiency, NM ... Nominal Mode, HO ... High Output_ Min. order quantity LLE 24x70mm QTY4: 36 pcs. The LLE24x70mm QTY4 module contains 4 single 24x70mm moduleswhich have to be separated_ Long lifetime up to 102,000 hours_ 5 years guarantee (conditions athttps://www.tridonic.com/en/int/services/manufacturerguarantee-conditions)Optical properties_ Colour temperatures 2,700, 3,000, 3,500, 4,000, 5,000 and 6,500K_ Efficacy of the LED module 205 lm/W at Irated and tp = 25 °C_ High colour rendering index CRI > 80_ High colour consistency (MacAdam 3) 1_ Small luminous flux tolerancesMechanical properties_ Module dimension 24 x 70 mm, 24 x 140 mm, 24 x 280 mm and 24x 560 mm (ZHAGA compliant)_ Simple installation via clips or screwsSystem solution_ Combine Tridonic's LED modules and dimmable drivers to achievean outstanding system efficacy (configuration possible viahttps://setbuilder.tridonic.com/)

Read more less

Product description_ Dimmable built-in constant current LED driver_ For luminaires of protection class I and protection class II_ Temperature protection as per EN 61347-2-13 C5e_ Adjustable output current via dip switch or DALI_ Selectable fixed output current 300, 350, 400, 450, 500, 550, 600,650, 700, 750, 800, 850, 900, 950, 1000 and 1050 mA (preselected current 300 mA)_ Max. output power 100 W_ Up to 93 % efficiency_ Anti-glowing design_ Nominal lifetime of 100,000 h_ 5 years guarantee (conditions athttps://www.tridonic.com/en/int/services/manufacturerguarantee-conditions)Housing properties_ Low profile metal casing with white cover_ Type of protection IP20Interfaces_ one4all (DALI-2, switchDIM, corridorFUNCTION)_ Terminal blocks: 0° push terminalsFunctions_ Adjustable output current in 1-mA-steps (DALI)_ Constant light output function (CLO)_ Protective features (overtemperature, short-circuit, overload, noload)_ Suitable for emergency escape lighting systems acc. to EN 50172Benefits_ Flexible configuration via companionSUITE (DALI)_ Application-oriented operating window for maximumcompatibility_ Best energy savings due to low stand-by losses and highefficiency

Read more less

June 2026 release. Product description- Dimmable built-in constant current LED driver- For luminaires of protection class I and protection class II- Temperature protection as per EN 61347-2-13 C5e- Adjustable output current via dip switch or DALI- Selectable fixed output current 900, 1050, 1200, 1400, 1500, 1650, 1800 and 1900 mA (pre-selected current 900 mA)- Max. output power 75 W- Up to 90 % efficiency- Nominal lifetime of 100,000 h- 5 years guarantee (conditions athttps://www.tridonic.com/en/int/services/manufacturerguarantee-conditions) Housing properties- Low profile metal casing with white cover- Type of protection IP20 Interfaces- one4all (DALI-2, switchDIM, corridorFUNCTION)- Terminal blocks: 0° push terminals Functions- Adjustable output current in 1-mA-steps (DALI)- Constant light output function (CLO)- Protective features (overtemperature, short-circuit, overload, noload)- Suitable for emergency escape lighting systems acc. to EN 50172 Benefits- Flexible configuration via companionSUITE (DALI)- Application-oriented operating window for maximum compatibility- Best energy savings due to low stand-by losses and high efficiency Typical applications- For linear/area lighting Websitehttp://www.tridonic.com/87501221

Read more less

June 2026 release. Product description- Dimmable built-in constant current LED driver- For luminaires of protection class I and protection class II- Temperature protection as per EN 61347-2-13 C5e- Adjustable output current via dip switch or DALI- Selectable fixed output current 500, 550, 600, 650, 700, 800, 900 and 1050 mA (pre-selected current 500 mA)- Max. output power 55 W- Up to 90 % efficiency- Nominal lifetime of 100,000 h- 5 years guarantee (conditions at https://www.tridonic.com/en/int/services/manufacturerguarantee-conditions) Housing properties- Low profile metal casing with white cover- Type of protection IP20 Interfaces- one4all (DALI-2, switchDIM, corridorFUNCTION)- Terminal blocks: 0° push terminals Functions- Adjustable output current in 1-mA-steps (DALI)- Constant light output function (CLO)- Protective features (overtemperature, short-circuit, overload, noload)- Suitable for emergency escape lighting systems acc. to EN 50172 Benefits- Flexible configuration via companionSUITE (DALI)- Application-oriented operating window for maximumcompatibility- Best energy savings due to low stand-by losses and highefficiency Typical applications- For linear/area lighting Websitehttp://www.tridonic.com/87501220

Read more less

June 2026 release. Product description- Dimmable built-in constant current LED driver- For luminaires of protection class I and protection class II- Temperature protection as per EN 61347-2-13 C5e- Adjustable output current via dip switch or DALI- Selectable fixed output current 250, 300, 350, 400, 450, 500, 600 and 700 mA (pre-selected current 250 mA)- Max. output power 35 W- Up to 88.5 % efficiency- Nominal lifetime of 100,000 h- 5 years guarantee (conditions at https://www.tridonic.com/en/int/services/manufacturerguarantee-conditions)  Housing properties- Low profile metal casing with white cover- Type of protection IP20 Interfaces- one4all (DALI-2, switchDIM, corridorFUNCTION)- Terminal blocks: 0° push terminals Functions- Adjustable output current in 1-mA-steps (DALI)- Constant light output function (CLO)- Protective features (overtemperature, short-circuit, overload, noload)- Suitable for emergency escape lighting systems acc. to EN 50172 Benefits- Flexible configuration via companionSUITE (DALI)- Application-oriented operating window for maximum compatibility- Best energy savings due to low stand-by losses and high efficiency  Typical applications- For linear/area lighting Websitehttp://www.tridonic.com/87501219

Read more less

28002091 - Discontinued NIMH 6 cell 7.2v 2.2AH battery We offer an unbranded version that is tested to work all Tridonic emergency gear! Typical 2-3 days delivery

Read more less

28002090 - Discontinued NIMH 5 cell 6v 2.2AH battery We offer an unbranded version that is tested to work all Tridonic emergency gear! Typical 2-3 days delivery

Read more less

28002089 - Discontinued NIMH 4 cell 4.8v 2.2AH battery We offer an unbranded version that is tested to work all Tridonic emergency gear! Typical 2-3 days delivery

Read more less

28002088 - Discontinued NIMH 3 cell 3.6v 2.2AH battery We offer an unbranded version that is tested to work all Tridonic emergency gear! Typical 2-3 days delivery

Read more less

28002087 - Discontinued NIMH 2 cell 2.4v 2.2AH battery We offer an unbranded version that is tested to work all Tridonic emergency gear! Typical 2-3 days delivery

Read more less

28002773 is discontinued NICD 3 cell 3.6v 4.5AH stick tagged battery We offer an unbranded version that is tested to work all Tridonic emergency gear! Typical 2-3 days delivery
