This item is now obsolete
Driver LC 20W 350mA fixC C SNC
essence series
Product description
Fixed output built-in LED driver
Constant current LED driver
For luminaires of protection class I and protection class II
Temperature protection as per EN 61347-2-13 C5e
Output current 350 mA
Max. output power 18.9 W
Nominal lifetime up to 50,000 h
5 years guarantee
Housing properties
Casing: polycarbonate, white
Type of protection IP20
Functions
Overload protection
Short-circuit protection
No-load protection
Burst protection voltage 1 kV
Surge protection voltage 1 kV (L to N)
Surge protection voltage 2 kV (L/N to earth)
Driver LC 15W 300/350mA fixC SC SNC2
essence series
Product description
Fixed output LED driver
Can be either used built-in or independent with clip-on strain-relief (see accessory)
Independent LED driver with cable clamps
Constant current LED driver
For luminaires of protection class II
Temperature protection as per EN 61347-2-13 C5e
Output current 300 or 350 mA
Max. output power 15 W
Nominal lifetime up to 50,000 h
5 years guarantee
Housing properties
Casing: polycarbonate, white
Type of protection IP20
Functions
Overload protection
Short-circuit protection
No-load protection
Burst protection voltage 1 kV
Surge protection voltage 0.5 kV (L to N)
Surge protection voltage 1 kV (L/N to earth)
Typical applications
For spot light and downlight in retail and hospitality applications
For panel light and area light in office and education application
Driver LC 38W 500-700mA flexC lp ADV
advanced series SELV
Product description
LED Constant current LED driver for luminaire installation
New version DC operating with EL marking
For luminaires of protection class I and protection class II
Output current adjustable between 500 – 700 mA
Temperature protection as per EN 61347-2-13 C5e
Max. output power 38 W
Up to 85 % efficiency
Nominal lifetime up to 100,000 h
5 years guarantee
Housing properties
Low profile metal casing with white cover
Type of protection IP20
Interfaces
Terminal blocks: 45° push terminals
Functions
Overload protection
Short-circuit protection
No-load protection
Overtemperature protection
Burst protection voltage 1 kV
Surge protection voltage 1 kV (L to N)
Surge protection voltage 2 kV (L/N to earth)
Suitable for emergency escape lighting systems acc. to IEC 50172
Typical applications
For linear/area lighting in office applications
Product description
Independent driver with strain-relief housing
Extra flat housing for constrained installation conditions (small ceiling cut outs and low ceiling voids)
Temperature protection as per EN 61347-2-13 C5e
Output current 350 mA
Max. output power 10 W
BIS approval mark for art. no.: 87500802, 87500804.
Nominal lifetime up to 50,000 h
Replacement for the 87500240 and 87500581
The Tridonic LCU 100/12 EO20 is a 100w 12v constant voltage LED driver with a universal input voltage range and a constant output voltage. This driver has an over temperature and overload protection, short circuit shutdown feature and automatic restart. This driver has a 5 year warranty. Tridonic article number: 24166327
Product description
Clip for fixation of LED modules with 4.3 mm holes
Fast snap on mounting (sheet thickness 0.5 – 1.0 mm for PUSH-FIX and 1 – 2 mm for PUSH-FIX Long)
For drilling hole 4 mm
Clip made of polycarbonate
Minimum sales quantity 500 pcs.
Product description
Emergency lighting LED driver for manual testing
For self-contained emergency lighting
For LED modules with a forward voltage of 40 – 97 V
SELV for output voltage < 120 V DC
Low profile casing (21 x 30 mm cross-section)
For luminaire installation
EM = Emergency
Nominal lifetime up to 100,000 h
5 years guarantee
Product description
Fits in most existing MR16 / GU10 halogen luminaires
10 W LED Equivalent to 50 W MR16 halogen with higher lumen output
Perfect solution for MR16 / GU10 replacement project
Module with integrated electronic, heatsink and optics
Compatible with leading and trailing edge phase cut dimmers
Dimming range 0.1 to 100 % (depends on dimmer)
Eye-catching lens optic with mirrors halogen facettes
Long lifetime: L70B50 >50,000 h at tp = 75 °C
5 years guarantee (conditions at https://www.tridonic.com/manufacturer-guarantee-conditions)
obsolete for alternative please click here
This is a 30w Tridonic dimmable built-in, constant current LED driver with an adjustable output current of 250-700mA. This driver has a max output power of 160w and an average life of 100,000 hours.
