Driver LC 150W 24V bDW SC PRE2
premium series 24 V – dimmable (IP20)
With strain-relief
Product description
NEW: lumDATA (Luminaire data, Energy reporting and Diagnostics & Maintenance)
Dimmable 24 V constant voltage LED driver for flexible constant voltage strips
Can bei either used built-in or independent with clip-on strain-relief (see data sheet chapter: 1. Standards)
The strain relief is included in both packaging variants. In the single packaging (SP) each Driver has also an individual packaging.
basicDIM Wireless enables different dimming options
Forms automatically a wireless communication network with up to 250 nodes
Dimming range 1 to 100 %
No additional external dimmer is needed
Suitable for emergency escape lighting systems acc. to EN 50172
Nominal lifetime up to 50,000 h
5 years guarantee
Typical applications
Cove lighting, facade accent lighting, ceiling integration
Technical details
24 V, 150 W
Small design (325 x 43 x 30 mm) with stretched-compact strain relief
Small cross section
Push terminals for simple wiring
Output terminals (+/–) equipped twice for more flexibility in the application
Interfaces
basicDIM Wireless
ready2mains (configuration via mains)
Terminal blocks: 45° push terminals
System solution
Tridonic LLE-FLEX ADV 600, 1,200, 1,800 lm/m
Tridonic LLE-FLEX EXC 600, 1,200, 1,800, 2,500 lm/m
In connection with Flex accessories wire to PCB plug
Test the function of third party light sources before use at low dimming levels to ensure the dimming function works perfectly
Data sheet
Driver LC 35W 24V bDW SC PRE2
premium series 24 V – dimmable (IP20)
With strain-relief
Product description
NEW: lumDATA (Luminaire data, Energy reporting and Diagnostics & Maintenance)
Dimmable 24 V constant voltage LED driver for flexible constant voltage strips
Can bei either used built-in or independent with clip-on strain-relief (see data sheet chapter: 1. Standards)
The strain relief is included in both packaging variants. In the single packaging (SP) each Driver has also an individual packaging.
basicDIM Wireless enables different dimming options
Forms automatically a wireless communication network with up to 250 nodes
Dimming range 1 to 100 %
No additional external dimmer is needed
Suitable for emergency escape lighting systems acc. to EN 50172
Nominal lifetime up to 50,000 h
5 years guarantee
Typical applications
Cove lighting, facade accent lighting, ceiling integration
Technical details
24 V, 35 W
Small design (195 x 43 x 30.2 mm) with stretched-compact strain relief
Small cross section
Push terminals for simple wiring
1 output channel (+/–)
Interfaces
basicDIM Wireless
ready2mains (configuration via mains)
Terminal blocks: 45° push terminals
System solution
Tridonic LLE-FLEX ADV 600, 1,200, 1,800 lm/m
Tridonic LLE-FLEX EXC 600, 1,200, 1,800, 2,500 lm/m
In connection with Flex accessories wire to PCB plug
Test the function of third party light sources before use at low dimming levels to ensure the dimming function works perfectly
Data sheet
basicDIM Wireless constant voltage LED ECG The 24V constant voltage LED driver LC 100/24V bDW SC PRE2 from the Premium series from Tridonic is suitable for luminaire installation or independent assembly. It has a rated power of 100 watts. Ideal areas of application are cove lighting, facade accent lighting and indirect ceiling lighting. In addition, the LED ECG is suitable for safety lighting systems in accordance with EN 50172. The LED driver automatically builds up a wireless communication network with up to 127 nodes. basicDIM Wireless enables various dimming options in a range from 1-100%, so that no external dimmer is required. Configuration via the network is possible with the help of ready2mains. CASAMBI-capable: light control via app The basicDIM Wireless LED driver also has the entire CASAMBI functionality: you can integrate it into any CASAMBI Bluetooth network and then control it very conveniently via the app on your smartphone or tablet. The housing of the LED ECG has a small design (295 x 43 x 30 mm) and a small cross-section. There are 45° push-in terminals for easy wiring. The output terminals (+/–) are duplicated – for more flexibility in use. The nominal service life is up to 50,000 hours. Tridonic offers a 5-year guarantee. We have summarized all information about the Casambi light management system again. Here you can download the CASAMBI app for free: for iOS/Apple/iPhone/iPad for iOS/AppleWatch for Android
Tridonic ELA 600x600mm 3800lm 840 ADV2
Edgelit panel for direct recessed mount and surface or suspended mount with accessories
With pre-installed connection cable and integrated plug
For suspended ceiling grid measure of 600, 625 mm and 1,200 x 300 mm
IK rating IK02
Product colour (frame) RAL 9003
Diffusor material standard article: PS, diffusor material TPA article (fullfills the TPA requirements): PS
Lightguide material: PMMA
HE ... High Efficiency, NM ... Nominal Mode, HO ... High Output
Orders only in full carton quantities.
Long lifetime: 50,000 hours
The Tridonic I-SELECT 2 PLUG 400MA BL plug is a ready-to-use resistor to set output current value. This is compatible with LED drivers featuring I-Select 2 interface and is not suitable for use with first generation I-Select interface. The resistor is based isolated, has a resistor power of 0.25w and is suitable for use with LED Driver series PRE and EXC. Tridonic article number: 28001112
The Tridonic LCI 35w 1050mA TEC C LED driver is a fixed output, constant current LED driver with a maximum output power of 35w. These drivers have an average life of 50,000 hours and a 5 year guarantee. The LCI 35w 1050ma TEC has over temperature and overload protection, as well as short circuit and no-load protection. Tridonic article number: 87500198
