The Ecopac ECP15-24VF-1 is a 24V constant voltage output LED Driver which features a compact, low profile design. These high quality LED drivers are supplied with 3 years warranty.  Protections: Short circuit/ Overload/ Overheat Input Voltage: 200 – 240VAC Cooling by free air convection Low cost, high reliability Output Power: 15W Compact and light-weight plastic case Working Temperature: -20C to +45C 3 year warrantyMore Information Manufacturer Ecopac Power Output Wattage (W) 15 Output Voltage 24V Dimmable (Type) No Dimensions 103x 35.5x 16 EMC Standards EN55015, EN61000-3-2, EN61000-3-3, EN61547 Input Voltage 200~240VAC Safety Standards EN61347-1, EN61347-2-13 Output Voltage Options Single Working Temperature -40~+85°C PDF Datasheet ECP15-VF-1.pdf

Read more less

EM converterLED BASIC NiCd/NiMH 50 V BASIC version Note: Supply of control gear with duration link in 3 hours position. Remove duration link for duration of 1 h. Duration link must be set before battery and mains connection. Product description Emergency lighting LED Driver for manual testing For self-contained emergency lighting For LED modules with a forward voltage of 10 – 54 V SELV for output voltage < 60 V DC Low profile casing (21 x 30 mm cross-section) For luminaire installation Nominal lifetime up to 100,000 h 5 years guarantee Properties Non maintained operation 1 or 3 h rated duration Operating time selectable with plug (duration link) Compatible with all dimmable and non-dimmable constant current LED Driver (see data sheet, LED Driver compatibility) 3-pole technology: 2-pole LED module changeover and delayed power switching for the LED Driver Automatic shutdown of output if LED load is out of range Constant power output Maximum light output for all LED modules Electronic charge system Deep discharge protection Short-circuit-proof battery connection Polarity reversal protection for battery Batteries High-temperature cells NiCd or NiMH batteries D, Cs or LA cells 4 year design life 1 year guarantee For battery compatibility refer to data sheet

Read more less

Product code manufacturer 186763 ?  Ballast LED Converter ?  Ballast version Surface-mounted with strain relief ?    Box quantity 1 ?  Brand Vossloh Schwabe ?  Dimmable Dali ?  Heigth 30,1mm ?  Input voltage 220V-240V ?  Length 130mm ?  Ouput current 300mA, 350mA, 400mA, 450mA, 500mA, 550mA, 600mA, 650mA, 700mA, 750mA, 800mA, 850mA, 900mA, 950mA, 1000mA, 1050mA ?  Power factor 0,95 ?  Shape Rectangular ?  Width 44,2mm ?

Read more less

This item is Obsolete the nearest alternative is the below   Alternative   Tridonic 89800393 EM PowLED HP Basic FX 80W LED Driver Tridonic 89800393 EM powLED HP BASIC FX 104 LP 80W 200V Linear LED Driver - High power emergency unit for linear LED lighting systems.Fixed-output LED Driver for mains operation with integrated Simple CORRIDOR FUNCTION.Emergency lighting function for use with single batteries for manual testing.Please see attached spec sheet for more information. Colours: As Per Picture Volts: 200-250 v Watts: 80 w Length: 360 mm Bulb/Lamp Type: LED Driver Size: 360 x 30 x 21 Height: 21 mm Width: 30 mm Weight: 275g

Read more less

Obsolete Alternative Up to 100W Alternative up to 60W   The Ecopac ELED-75-24D DALI Dimmable LED Driver is 75W 24VDC output.  Constant Voltage  / PWM Output Design Dali & Push Dimmable Protections: Short circuit/ Over Voltage/ Over Temperature Other features: Dimming range from 0.1% to 100% Input Range 200-265VAC Output 24VDC Built-in PFC function IP20design for indoor or outdoor installations 87% efficiency 3 years warrantyMore Information Manufacturer Ecopac Power Output Wattage (W) 75 Output Voltage 24V Dimmable (Type) DALI, Push Dimming DC Output Adjustment No Dimensions 355 x 215 x 215 mm EMC Standards Compliance to EN55015, EN61000-3-2, EN61000-3-3 (?60% load), EN61000-4-2,3,4,5,6,11, EN61547 Input Voltage 100-265VAC Safety Standards EN61347-1, EN61347-2-13, EN62493, IP20 Output Voltage Options Single Working Temperature -40 ~ +60°C PDF Datasheet ELED-75-D.pdf

Read more less

ELED-40-C300/1400DP2 Features: 40W DALI 2 and Push Dimming Multiple-Stage Output Current LED Driver Features: • Constant Current mode output with multiple levels selectable by dip switch• DALI 2 dimming function (IEC62386)• AC input: 100-277VAC• Built-in active PFC function• Efficiency up to 86%• Protections: Short circuit/ Over load/Over temperature• Cooling by free air convection• Suitable for intelligent LED lighting ELED-C40-300/1400DP2(1400) ELED-C40-300/1400DP2(1300) ELED-C40-300/1400DP2(1200) ELED-C40-300/1400DP2(1100) ELED-C40-300/1400DP2(1000) ELED-C40-300/1400DP2(900) ELED-C40-300/1400DP2(800) ELED-C40-300/1400DP2(700) ELED-C40-300/1400DP2(650) ELED-C40-300/1400DP2(600) ELED-C40-300/1400DP2(550) ELED-C40-300/1400DP2(500) ELED-C40-300/1400DP2(450) ELED-C40-300/1400DP2(400) ELED-C40-300/1400DP2(350) ELED-C40-300/1400DP2(300) Wattage 40 40 40 40 40 40 40 40 40 39 35.8 32.5 29.3 26 22.8 19.5 Input Voltage 100~277VAC 100~277VAC 100~277VAC 100~277VAC 100~277VAC 100~277VAC 100~277VAC 100~277VAC 100~277VAC 100~277VAC 100~277VAC 100~277VAC 100~277VAC 100~277VAC 100~277VAC 300mA Output Current 1400mA 1300mA 1200mA 1100Ma 1000mA 900mA 800mA 700mA 650mA 600mA 550mA 500mA 450mA 400mA 350mA 3~65 Output Voltage 3~29 3~31 3~34 3~37 3~40 3~45 3~50 3~57 3~62 3~65 3~65 3~65 3~65 3~65 3~65 Dimensions 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm 171.5 x 54x 20 mm Working Temperature -40~80°C Safety Standards EN61347-1, EN61347-2-13, UL8750 EMC Standards Compliance to EN55015, EN61000-3-2,3 (≥50% load), FCC Part 15B

Read more less

Driver LC 25W 350–1050mA flexC SC EXC excite series With strain-relief Product description Constant current LED driver Can be either used built-in or independent with clip-on strain-relief (see accessory) Adjustable output current between 350 and 1,050 mA via ready2mains Programmer or I-SELECT 2 plugs Max. output power 25 W Up to 86 % efficiency Nominal lifetime up to 100,000 h 5 years guarantee Housing properties Casing: polycarbonate, white Type of protection IP20 Interfaces ready2mains (configuration via mains) Terminal blocks: 45° push terminals Functions Adjustable output current in 1-mA-steps (ready2mains, I-SELECT 2) Protective features (overtemperature, short-circuit, overload, no-load, input voltage range) Suitable for emergency escape lighting systems acc. to EN 50172 Benefits Application-oriented operating window for maximum compatibility Best energy savings due to high efficiency Flexible configuration via ready2mains and I-SELECT 2 Typical applications For downlight, spotlight and decorative applications   Data sheet

Read more less

Obsolete, please order the below  Alternative    https://www.easy-controlgear.com/products/ecxd1050-299-sr-186763-vossloh-schwabe?_pos=1&_sid=e471d17bd&_ss=r Specifications Technical data Information Brand Harvard Power Systems Commodity 8504409090 Item number CL350D2-240-C Warranty pack 60 Months Bring-In Series CL RoHS Compliant Description AC-DC 33W LED driver Constant Current mode (CC); Max. output 48Vdc at 0.35A; IP20; Dimming with DALI; Remote control Packing Quantity 40 Application LED EN 61347 Net weight (gram) 130 Technology AC/DC Constant Current C.C. Format Box Type - Enclosed Output Power (W) 33 Output Voltage (V) 48 Output Current (A) 0.35 Input Voltage (V) 220 - 240 IP Rating IP20 Width (mm) 32 Height (mm) 32 Depth (mm) 180 Control Signals Remote Sense Dimming Technology DALI

Read more less

Product description NEW: lumDATA (DALI-2 part ext. 251, 252 and 253) Constant current built-in LED driver, particularly suitable for industrial applications in tough environments with elevated ambient temperatures such as cold warehouses or factories Dimming range 1 to 100 % Output current adjustable between 200 – 850 mA Max. output power 100 W Suitable for mains voltage peaks (burst/surge) up to 4 kV Expanded temperature range of -40 ... +70 °C Nominal lifetime up to 100,000 h (at ta 60 °C) 8 years guarantee

Read more less

LED Driver 240v 33w 500/1000ma - Harvard - CL1000S-240-C

Read more less

Product description NEW: lumDATA (DALI-2 part ext. 251, 252 and 253) Dimmable built-in constant current LED driver Dimming range 1 to 100 % For luminaires of protection class I and protection class II Output current adjustable between 350 – 1,050 mA via ready2mains Programmer, I-SELECT 2 plugs or DALI Max. output power 75 W Up to 92 % efficiency Power input on stand-by < 0.16 W Nominal lifetime up to 100,000 h 5 years guarantee Housing properties Low profile metal casing with white cover Type of protection IP20 Interfaces one4all (DALI-2 DT 6, DSI, switchDIM, corridorFUNCTION) ready2mains (configuration and dimming via mains) Terminal blocks: 0° push terminals Functions Adjustable output current in 1-mA-steps (DALI, ready2mains, I-SELECT 2) Fulfills DALI-2 parts: 251 (Luminaire data), 252 (Energy reporting) and 253 (Diagnostics & Maintenance) Constant light output function (CLO) Power-up fading at AC Configurable via ready2mains Switch off the driver with fade2zero Service monitor to log certain events Protective features (overtemperature, short-circuit, overload, no-load, input voltage range, reduced surge amplification) Intelligent Voltage Guard (overvoltage and undervoltage monitoring) Suitable for emergency escape lighting systems acc. to EN 50172 Benefits Flexible configuration via companionSUITE Application-oriented operating window for maximum compatibility Best energy savings due to low stand-by losses and high efficiency Flexible configuration via DALI, ready2mains and I-SELECT 2 Reliability proven by lifetime up to 100,000 h and 5 years guarantee Typical applications For linear/area lighting in office applications

Read more less

OMNI-LED FLEXITM ARTICULATED LED REMOTE BOX EMERGENCY CONVERSION SOLUTIONS Product Overview Effective solution for emergency conversion of luminaires Articulated design allows installation through a ceiling cut-out of just 55mm diameter Removable end covers provide easy wiring access Ideal for use with LED panels or downlights Available with pre-wired cable assemblies for ‘plug-and-play’ convenience Available with DALI Self-Test functionality 3 hour operation using high temperature Nickel Cadmium or Nickel Metal Hydride cells Designed and manufactured in Great Britain Technical Data Input Supply Voltage 230V +/- 10% Supply Frequency 50/60 Hz Output Voltage Range 9 – 200 VDC Battery Type 2.4V NiCd, 3.6V NiCd or 4.8V NiMH Ambient Temperature Range 5°C – 35°C Battery Charge Time 24 Hours Earth Leakage Current <0.5mA IP Rating IP20
