The Tridonic PC 2/55 TCL PRO is a non-dimmable high frequency ballast to run: 2 x 55 Watt long single turn compact fluorescent lamps. Click here to see Data Sheet and Wiring Diagrams!
Cheaper Alternative
osram-qtp-optimal-2x54-58-4008321880253
This item is obsolete, please co0nsider either of the below as viable alternatives
Alternative 1
Alternative 2
Tridonic Electronic Emergency Lighting Module 230/240v 50/60/Hz HT Nicd 3 Cells
1 x28-33w 3hr 3Cell TC-DD Low Output Combo HF Ballast - Tridonic - 89899943 / 89899943
Tridonic 89899980 PC1X28-33LOEDD Emergency Combo for CFL
Combination electronic ballast and emergency lighting unit. For use with TC-DD compact fluorescent lamps. 3 hour rated duration, short circuit proof battery connection. NiCd batteries, separate battery pack with high temperature cells.
Volts:
240 v
Length:
123 mm
Width:
31 mm
Diameter:
31 mm
Bulb/Lamp Type:
Ballast
Height:
79 mm
Technology:
Compact Fluorescent
NiCd Accus 4.5 Ah
Nickel-Cadmium cells (NiCd)
Fig. 1: Stick; Connection: blade terminal
Product description
High-temperature NiCd cells for use with emergency lighting units
4 year design life
1 year guarantee from delivery date
Properties
Constant high-temperature operation – depending on the emergency lighting unit used (refer to respective emergency control gear data sheet)
Good charging properties at high temperature
High energy maintenance of the charged battery
Certified quality manufacturer
In various configurations
Simple connection with blade terminal respectively plug terminal
With polycarbonate fixing caps and connecting cable
Electrical connection with mounted end caps possible
Suitable for emergency lighting equipment as per IEC 60598-2-22
Product description
Independent driver with strain-relief housing
Extra flat housing for constrained installation conditions (small ceiling cut outs and low ceiling voids)
Temperature protection as per EN 61347-2-13 C5e
Output current 350 mA
Max. output power 10 W
BIS approval mark for art. no.: 87500802, 87500804.
Nominal lifetime up to 50,000 h
Replacement for the 87500240 and 87500581
Electronic ballast with highest possible energy class CELMA EEI A2 BAT. It offers large temperature range, intelligent voltage guard, precise lamp operation using adjustment of lamp parameters, advanced SMART-Heating for minimum 50000 starts without replacement of lamps, constant luminous flux irrespective of fluctuations in mains voltage, designed for THD <10%, for luminaires of protection class I and protection class II. It features automatic start after replacement of defective lamps, safety shutdown of defective lamps and at end of lamp life (EOL 2), insulation displacement connection (IDC) terminal for rapid automatic or manual wiring and for emergency lighting systems as per EN 50172.
· Rated lifespan: 100,000 hours
· Flicker free warm start
· Min/Max ambient working temperature: -25°C to 70°C
· Degree of protection: IP20
· Operating voltage: 198-264V (AC), 176-280V (DC)
Driver LC 38W 250-350mA flexC lp ADV
advanced series non-SELV
Product description
LED Constant current LED driver for luminaire installation
New version DC operating with EL marking
For luminaires of protection class I and protection class II
Temperature protection as per EN 61347-2-13 C5e
Output current adjustable between 250 – 350 mA
Max. output power 38 W
Up to 88.5 % efficiency
Nominal lifetime up to 100,000 h
5 years guarantee
Housing properties
Low profile metal casing with white cover
Type of protection IP20
Interfaces
Terminal blocks: 45° push terminals
Functions
Overload protection
Short-circuit protection
No-load protection
Burst protection voltage 1 kV
Surge protection voltage 1 kV (L to N)
Surge protection voltage 2 kV (L/N to earth)
Typical applications
For linear/area lighting in office applications
Driver LCA 100W 24V one4all SC PRE
premium series 24 V – dimmable (IP20)
With strain-relief
Product description
NEW: lumDATA (Luminaire data, Energy reporting and Diagnostics & Maintenance)
Dimmable 24 V constant voltage LED driver for flexible constant voltage strips
Can bei either used built-in or independent with clip-on strain-relief (see data sheet chapter: 1. Standards)
One4all interface and ready2mains enable different dimming options
Dimming range 1 to 100 %
No additional external dimmer is needed
Suitable for emergency escape lighting systems acc. to EN 50172
Nominal lifetime up to 50,000 h
5 years guarantee
Typical applications
Cove lighting, facade accent lighting, ceiling integration
Technical details
24 V, 100 W
Small design (295 x 43 x 30 mm) with stretched-compact strain relief
Small cross section
Push terminals for simple wiring
Output terminals (+/–) equipped twice for more flexibility in the application
Interfaces
one4all (DALI DT 6, DSI, switchDIM, corridorFUNCTION)
ready2mains (configuration and dimming via mains)
Terminal blocks: 45° push terminals
System solution
Tridonic LLE-FLEX ADV 600, 1,200, 1,800 lm/m
Tridonic LLE-FLEX EXC 600, 1,200, 1,800, 2,500 lm/m
In connection with Flex accessories wire to PCB plug
Test the function of third party light sources before use at low dimming levels to ensure the dimming function works perfectly
Obsolete , please order the successor below
Alternative
Driver LC 38W 700mA fixC lp SNC2
essence series SELV
Product description
Fixed output built-in LED driver
Constant current LED driver
For luminaires of protection class I and protection class II
Temperature protection as per EN 61347-2-13 C5e
Output current 700 mA
Max. output power 37.8 W
Up to 86 % efficiency
Nominal lifetime up to 50,000 h
5 years guarantee
Housing properties
Casing: metal, white
Type of protection IP20
Functions
Overload protection
Short-circuit protection
No-load protection
Product description
High-temperature NiCd battery pack for use with emergency lighting units
4 year design life
1 year guarantee from delivery date
Properties
Constant high-temperature operation
Temperature depending on the used emergency lighting unit (refer to respective emergency control gear data sheet)
Good charging properties at high temperature
High energy maintenance of the charged battery
Certified quality manufacturer
Casing material made of polycarbonate
1.0 m integrated double-insulated cable
1.0 mm² solid wire, pre-stripped
Suitable for emergency lighting equipment as per IEC 60598-2-22
Product description
Fixed output built-in LED driver
Constant current LED driver
For luminaires of protection class I and protection class II
Temperature protection as per EN 61347-2-13 C5e
KC certificate for LC 60W 1400mA fixC C SNC
Output current 1,400 mA
Max. output power 60 W
KC approval mark for art. no.: 87500568 and 87500570.
Nominal lifetime up to 50,000 h
5 years guarantee (conditions at www.tridonic.com)
Housing properties
Casing: polycarbonate, white
Type of protection IP20
Functions
Overtemperature protection
Overload protection
Short-circuit protection
No-load protection
EAN/UPC: 9006210603384
Country of Origin: CN
Customs tariff No.: 85044083
