Obsolete , please order 28002472
Driver LC 19W 350mA fixC lp SNC2
Linear drivers
Data sheet
Product description
Fixed output built-in LED driver
Constant current LED driver
For luminaires of protection class I and protection class II
Temperature protection as per EN 61347-2-13 C5e
Output current 350 mA
Max. output power 18.9 W
Up to 88 % efficiency
Nominal lifetime up to 50,000 h
5 years guarantee (conditions at www.tridonic.com)
This item is now obsolete , you wil have to order a sepersate ballast and inverotr . Please call 01462 490066 for guidance
Tridonic PC2x18-4C COMBO HF Ball/Emcy 240/250v 50/60/0Hz to run 2x18w T8 Tubes
EM powerLED BASIC FX SC MH/NiCd 32 W
Combined emergency lighting LED driver
Product description
Combined emergency LED driver for manual testing
For self-contained emergency lighting
Can be either used built-in or independent with clip-on strain-relief (see accessory)
Max. output power 32 W
Nominal lifetime up to 100,000 h
5 years guarantee
Functions
Adjustable output current between 350 and 700 mA via I-SELECT 2 plugs
Protective features (overtemperature, short-circuit, overload, no-load, input voltage range)
Suitable for emergency escape lighting systems acc. to EN 50172
1 or 3 h rated duration depending on connected battery
Constant power output in emergency mode
Battery management
Intelligent charge system
Deep discharge protection
Polarity reversal protection for battery
Short-circuit-proof battery connection
Batteries
NiCd or NiMH batteries
4 year design life
1 year guarantee
For battery compatibility refer to datasheet, battery selection
The Tridonic PC 1x18-3 TC COMBO is an electronic combination ballast and emergency lighting unit to run 1 x 18w Triple Turn compact fluorescent lamps. It has a 3 hour emergency duration and should be used with a 3 cell battery pack. The combo ballast features a slim and lighweight compact housing. Tridonic article number:Tridonic article number: 89899990. Tridonic product comes with a 5 year warranty.
Dimensions:Length: 123mmWidth: 102mmHeight: 31mm
Product description
Ideal for linear and panel lights
2 terminals for serial wiring
Perfectly uniform light, even if several LED modules are used together in a line
Push terminals for quick and simple wiring of LED module to LED module
Option backside terminal
Broad portfolio from extruded lenses and covers available
Long lifetime up to 72,000 hours
Driver LCO 165W 200–1050mA 285V one4all NFC C EXC3
excite NFC outdoor series
Product description
Dimmable built-in constant current LED driver
Dimming range 5 – 100 % (min. 10 mA)
For luminaires of protection class I and protection class II
Temperature protection as per EN 61347-2-13 C5e
Output current adjustable between 200 – 1,050 mA via NFC, DALI or ready2mains Programmer
Max. output power 165 W
Up to 93 % efficiency
Lowest power input on stand-by < 0.16 W
Nominal lifetime of 100,000 h and 8 years guarantee
Interfaces
Near field communication (NFC)
one4all (DALI DT 6, DSI, switchDIM, corridorFUNCTION)
ready2mains (configuration via mains)
U6Me2 (configuration of chronoSTEP 2 via mains)
Terminal blocks: 45° / 0° push terminals
Functions
Adjustable output current in 1-mA-steps (NFC, DALI, ready2mains)
Programmable chronoSTEP: times and levels (NFC, DALI, U6Me2, ready2mains)
Dimming through mains voltage (inputDIM)
Enhanced constant light output function (eCLO)
Protective features (overtemperature, short-circuit, overload, no-load, input voltage range, reduced surge amplification)
Configurable external temperature management (ETM)
Intelligent Temperature Guard (ITG)
Intelligent Voltage Guard Plus (IVG+)
Suitable for emergency escape lighting systems acc. to EN 50172
Benefits
Flexible configuration via companionSUITE (NFC, DALI, ready2mains™) or U6Me2 programmer
Application-oriented operating window for maximum compatibility
Best energy savings due to low stand-by losses and high efficiency
In-field programming possible after installation with NFC interface and ready2mains
High overvoltage protection: up to 10 kV asymmetric (protection class I and II)
Typical applications
Road, street and industry
Driver LCA 60W 900–1750mA one4all SR PRE
premium series
Product description
NEW: lumDATA (DALI-2 part ext. 251, 252 and 253)
Independent dimmable constant current LED driver with strain-relief
Dimmable via DALI / DALI-2
Dimming range 1 – 100 % (whole operating window)
Output current adjustable between 900 – 1,750 mA via ready2mains Programmer, I-SELECT 2 plugs or DALI
Max. output power 60 W
Up to 90 % efficiency
Power input on stand-by < 0.2 W
Nominal lifetime up to 100,000 h
5 years guarantee
Housing properties
Casing: polycarbonate, white
Type of protection IP20
Strain relief with loop through function
Interfaces
one4all (DALI-2 DT 6, DSI, switchDIM, corridorFUNCTION)
ready2mains (configuration and dimming via mains)
Terminal blocks: 0° / 45° push terminals (input / output)
Functions
Adjustable output current in 1-mA-steps (DALI, ready2mains, I-SELECT 2)
Fulfills DALI-2 parts: 251 (Luminaire data), 252 (Energy reporting) and 253 (Diagnostics & Maintenance)
Constant light output function (CLO)
Power-up fading at AC
Configurable via ready2mains
Switch off the driver with fade2zero
Service monitor to log certain events
Protective features (overtemperature, short-circuit, overload, no-load, input voltage range, reduced surge amplification)
Suitable for emergency escape lighting systems acc. to EN 50172
For cable cross-sections up to 2.5 mm²
Benefits
Application-oriented operating window for maximum compatibility
Best energy savings due to low stand-by losses and high efficiency
Flexible configuration via DALI, ready2mains and I-SELECT 2
No tools required for installation
Typical applications
For downlight, spotlight and decorative applications
Please select the MA rating you will be running it at and we will include the correct resistor
Product description
Independent fixed output LED driver
For luminaires of protection class I and protection class II
For luminaires with M and MM as per EN 60598, VDE 0710 and VDE 0711
Temperature protection as per EN 61347-2-13 C5e
Adjustable output current between 700, 900 and 1,050 mA
Max. output power 42 W
Up to 88 % efficiency
Nominal lifetime up to 50,000 h
5 years guarantee
Housing properties
Casing: polycarbonate, white
Type of protection IP20
Interfaces
Input terminals: 0° screw terminals
Output terminals: 45° push terminals
Functions
Overload protection
Short-circuit protection
No-load protection
Overtemperature protection
Burst protection voltage 1 kV
Burst protection voltage 1 kV (L to N)
Surge protection voltage 2 kV (L/N to earth)
Typical applications
For spot light and downlight in retail and hospitality applications
For panel light and area light in office and education application
