Data sheet
Product description
Constant current LED driver
Adjustable output current between 150 and 400 mA via ready2mains Programmer or I-SELECT 2 plugs
Max. output power 10 W
Up to 81 % efficiency
Nominal lifetime up to 100,000 h
5 years guarantee (
The Tridonic EM 04 ST G2 (selftest) is one of the latest emergency inverters on the market. Designed to be used with linear and compact fluorescent lamps 16-26w with a 4 cell NiCad battery. Can be used with non dimmable and dimmable setups. See link for all product features Tridonic EM 04 SELFTEST G2 (NiCad) Manufacturer part number 89800201
We have very limited stock left ! 30/8/22
please read below
This combi unit is now obsolete, we would suggest space permitting using the 2 below items as a viable alternative.
Emergency Invertor uses a 4 cell battery ( Supplied Separately )
https://www.easy-controlgear.com/products/elp-om458-ep-4cell-tct-t5-2d-emergency-module?_pos=1&_sid=5a063deac&_ss=r
2 X 58W Ballast
https://www.easy-controlgear.com/products/philips-hfp258tldiii-ph-hf-p-2x58-tl-d-iii-220-240v-50-60hz-id?_pos=1&_sid=be327a0ae&_ss=r
Tridonic T8 Combo High Frequency Ballast 2 x 58w from Tridonic
Model: 89805272
Designed for use with Twin T8 (25mm diameter) Fluorescent Lamps rated at 58 watts this Tridonic Combo HF Ballast features a 3 hour emergency duration and hot lamp restart in normal operation. A combination of electronic ballast and emergency lighting unit this gear manually tests emergency lighting functions and guarantees light output in the event of mains failure.
Technical Specifications
Control Gear Type
Emergency
Wattage
58 W
Manufacturer
Tridonic
Dimming?
Non-Dimmable
No. Of Lamps
Twin (2x)
Cells
4 (4.8v)
Depth
28 mm
Lamp
2 x 58w T8
Length
424 mm
Type
Control Gear
Width
42 mm
Compatible Lamp Type
T8
Manufacturer Part Number
89805270
Control Gear Technology
Fluorescent
Obsolete , please order 28002472
Driver LC 19W 350mA fixC lp SNC2
Linear drivers
Data sheet
Product description
Fixed output built-in LED driver
Constant current LED driver
For luminaires of protection class I and protection class II
Temperature protection as per EN 61347-2-13 C5e
Output current 350 mA
Max. output power 18.9 W
Up to 88 % efficiency
Nominal lifetime up to 50,000 h
5 years guarantee (conditions at www.tridonic.com)
This item is now obsolete , you wil have to order a sepersate ballast and inverotr . Please call 01462 490066 for guidance
Tridonic PC2x18-4C COMBO HF Ball/Emcy 240/250v 50/60/0Hz to run 2x18w T8 Tubes
EM powerLED BASIC FX SC MH/NiCd 32 W
Combined emergency lighting LED driver
Product description
Combined emergency LED driver for manual testing
For self-contained emergency lighting
Can be either used built-in or independent with clip-on strain-relief (see accessory)
Max. output power 32 W
Nominal lifetime up to 100,000 h
5 years guarantee
Functions
Adjustable output current between 350 and 700 mA via I-SELECT 2 plugs
Protective features (overtemperature, short-circuit, overload, no-load, input voltage range)
Suitable for emergency escape lighting systems acc. to EN 50172
1 or 3 h rated duration depending on connected battery
Constant power output in emergency mode
Battery management
Intelligent charge system
Deep discharge protection
Polarity reversal protection for battery
Short-circuit-proof battery connection
Batteries
NiCd or NiMH batteries
4 year design life
1 year guarantee
For battery compatibility refer to datasheet, battery selection
The Tridonic PC 1x18-3 TC COMBO is an electronic combination ballast and emergency lighting unit to run 1 x 18w Triple Turn compact fluorescent lamps. It has a 3 hour emergency duration and should be used with a 3 cell battery pack. The combo ballast features a slim and lighweight compact housing. Tridonic article number:Tridonic article number: 89899990. Tridonic product comes with a 5 year warranty.
Dimensions:Length: 123mmWidth: 102mmHeight: 31mm
Product description
High-temperature NiCd battery pack for use with emergency lighting units
4 year design life
1 year guarantee from delivery date
Properties
Constant high-temperature operation
Temperature depending on the used emergency lighting unit (refer to respective emergency control gear data sheet)
Good charging properties at high temperature
High energy maintenance of the charged battery
Certified quality manufacturer
Casing material made of polycarbonate
1.0 m integrated double-insulated cable
1.0 mm² solid wire, pre-stripped
Suitable for emergency lighting equipment as per IEC 60598-2-22
