Fully programmable via software (DALI Interface)
Flexible current setting (LEDset2)
Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
High-quality dimming of 1…100 % by amplitude dimming (except 80 W versions)
High quality of light thanks to <1% output ripple current
Very high efficiency
Very low standby power consumption: < 0.15 W *
Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
The Ecopac Power ECP150-12VF-1 slimline constant voltage LED driver is ideal for concealment where space is restricted, such as hiding behind a strip. Short circuit, over temperature and over loading protection are all standard features. Ecopac Power LED Drivers are supplied with a 3 year warranty. Other features: Slim line LED Driver Universal AC input/ Full range 180-264VAC Input Frequency 50/60Hz 12V Constant voltage output 3 years warrantyMore Information Manufacturer Ecopac Power Output Wattage (W) 150 Output Voltage 24V Dimmable (Type) No DC Output Adjustment N/a EMC Standards EN55015, EN61000-3-2; EN61000-4-2,3,4,5,6 EN61547 Input Voltage 180-264VAC Safety Standards EN61347-1,EN61347-2-13 Working Temperature -20~+45°C
This is a TCI 55w 1050mA MaxiJolly Dali dimmable constant current LED driver. The full features list is as follows:
•Multipower driver supplied with dip-switch for the selectionof the output current.•IP20 independent driver, for indoor use(DC MAXI JOLLY HC/2 DALI).•Class I protection against electric shock for direct or indirectcontact (DC MAXI JOLLY HC/2 DALI).•Driver for built-in use (DC MAXI JOLLY HC DALI BI).•It can be used for lighting equipment in protection class I.•Active Power Factor Corrector.•Analogical input (NTC) for thermal sensor connection.•Auxiliary output 12 V max. 100 mA.•Current regulation ±5 % including temperature variations.•Input and output terminal blocks on the same side(wire cross-section up to 1,5 - 2,5 mm2/ AWG15 - AWG13).•Clamping screws on primary and secondary circuits for cableswith diameter: min. 3 mm - max. 8 mm (DC MAXI JOLLY HC/2DALI).•Protections:- against overheating and short circuits;- against mains voltage spikes;- against overloads.•Thermal protection = C.5.a.
Operation mode:
Operation Mode•Light regulation 0/0,5 - 100 % by means of PUSH function, 0/1...10 V interface(I=1 mA) or 100 Kohm potentiometer and DALI.•Features DALI dimming:- memory function for sets or light groups;- recall of stored functions;- compatible with standard DALI interfaces.•Light regulation 0/0,5 - 100 % by means of PUSH function (mains voltage):- a short push to turn on and off;- a longer push to increase or decrease light intensity;- regulation automatically stops at minimum and maximum values;- for another on, regulation or off command, release the push button and givethe desired command again.- dimming level memory at mains restore.•Possibility to use PUSH function to 4/5 drivers without sync cable.•Maximum length of the cable, from push button to last driver, must bemax. 15 m / 49 ft. In case of applications where the cable is longer than15 m / 49 ft, keep this separate from the 110 - 240 Volt mains cable.•ATTENTION: only use normally open push buttons with no incorporatedwarning light.•Specific dimming terminal connection with a 0/1...10 Vdc electronicpotentiometer (0/1…10 V local dimming, double insulation required forexternal connection).•Max. 10 synchronised drivers of which only one can be controlled(1 Master + 9 Slaves).•Synchronization cable is separately supplied.
The Tridonic I-SELECT 2 PLUG 400MA BL plug is a ready-to-use resistor to set output current value. This is compatible with LED drivers featuring I-Select 2 interface and is not suitable for use with first generation I-Select interface. The resistor is based isolated, has a resistor power of 0.25w and is suitable for use with LED Driver series PRE and EXC. Tridonic article number: 28001112
Constant CurrentFully isolated plastic caseProtections: Short circuitOther features:Universal AC input / Full RangeSmall and compact sizeNo load power consumption <0.5WIP30 designClass II power unit, no FGCooling by free air convectionPass LPS100% full load burn-in testLow cost, High reliability2 years warrantyMore Information
Manufacturer
Mean Well
Output Wattage (W)
8
Output Current
700mA
Dimmable (Type)
No
Output Voltage Range (V)
5~11
Dimensions
60 x 30 x 22
EMC Standards
EN55015, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547 ; light industry level (surge 2KV), Criteria A
Input Voltage
90~264VAC; 127~370VDC
Safety Standards
Design refer to UL8750, CSA C22.2 No.250.0-08; ENEC EN61347-1, EN61347-2-13
Output Voltage Options
Single
Working Temperature
-30~+70°C
PDF Datasheet
APC-8-spec.pdf
The Tridonic LCI 35w 1050mA TEC C LED driver is a fixed output, constant current LED driver with a maximum output power of 35w. These drivers have an average life of 50,000 hours and a 5 year guarantee. The LCI 35w 1050ma TEC has over temperature and overload protection, as well as short circuit and no-load protection. Tridonic article number: 87500198
Mean Well 12W and 16W Constant Voltage LED Driver / Power Supply - APV Series
APV series 12W and 16W constant voltage LED driver / power supply with universal AC input. These low cost, highly reliable LED drivers / power supplies have a fully isolated plastic case and suitable uses include LED lighting and moving sign applications.
Full range universal AC inputSmall, compact, fully isolated plastic caseFree air convection cooling100% full load burn-in testShort circuit, overload and over voltage protectionPass LPSEMC compliance to EN55022 (CISPR22) Class B, EN55015, EN61547Harmonic current compliance to EN61000-3-2 Class A, EN61000-3-3
Note
For Industrial Use Only, not in scope of Regulation (EC) No 125/2009.MTBF to MIL-HDBK-217F12W versions: Derate output above 40°C 16W versions: Derate output above 40°C
Standards
Design refer to TUV EN60950-1, EN61347-2-13, UL8750
Mean Well 12W and 16W Constant Voltage LED Driver / Power Supply - APV Series
APV series 12W and 16W constant voltage LED driver / power supply with universal AC input. These low cost, highly reliable LED drivers / power supplies have a fully isolated plastic case and suitable uses include LED lighting and moving sign applications.
Full range universal AC inputSmall, compact, fully isolated plastic caseFree air convection cooling100% full load burn-in testShort circuit, overload and over voltage protectionPass LPSEMC compliance to EN55022 (CISPR22) Class B, EN55015, EN61547Harmonic current compliance to EN61000-3-2 Class A, EN61000-3-3
Note
For Industrial Use Only, not in scope of Regulation (EC) No 125/2009.MTBF to MIL-HDBK-217F12W versions: Derate output above 40°C 16W versions: Derate output above 40°C
Standards
Design refer to TUV EN60950-1, EN61347-2-13, UL8750
Driver LCA 10W 150–400mA one4all SC PRE
premium series
With strain-relief
Product description
NEW: lumDATA (DALI-2 part ext. 251, 252 and 253)
Dimmable built-in constant current LED driver
Can be either used built-in or independent with clip-on strain-relief (see accessory)
Dimming range 1 to 100 %
For luminaires of protection class I and protection class II
Output current adjustable between 150 – 400 mA via ready2mains Programmer, I-SELECT 2 plugs or DALI
Max. output power 10 W
Up to 82 % efficiency
Power input on stand-by < 0.2 W
Nominal lifetime up to 100,000 h
5 years guarantee
Housing properties
Casing: polycarbonate, white
Type of protection IP20
Interfaces
one4all (DALI-2 DT 6, DSI, switchDIM, corridorFUNCTION)
ready2mains (configuration and dimming via mains)
Terminal blocks: 45° push terminals
Functions
Adjustable output current in 1-mA-steps (DALI, ready2mains, I-SELECT 2)
Fulfills DALI-2 parts: 251 (Luminaire data), 252 (Energy reporting) and 253 (Diagnostics & Maintenance)
Constant light output function (CLO)
Power-up fading at AC
Configurable via ready2mains
Switch off the driver with fade2zero
Service monitor to log certain events
Protective features (overtemperature, short-circuit, overload, no-load, input voltage range, reduced surge amplification)
Suitable for emergency escape lighting systems acc. to EN 50172
Benefits
Application-oriented operating window for maximum compatibility
Best energy savings due to low stand-by losses and high efficiency
Flexible configuration via DALI, ready2mains and I-SELECT 2
Typical applications
For linear/area lighting in office applications
Constant current designIP66 ratedProtections: Short circuit/ Overload/ Over temp.Input Voltage: 100 – 240VACCooling by free air convectionLow cost, high reliabilityOutput Power: 4WCompact and light-weight plastic caseWorking Temperature: 0°C to +45°C2 year warrantyMore Information
Manufacturer
Ecopac Power
Output Wattage (W)
10
Output Current
500mA
Dimmable (Type)
No
Output Voltage Range (V)
9.5 Max
Dimensions
38x 30x 23.5
EMC Standards
EN55015, EN61000-3-2, EN61000-3-3, EN61547
Input Voltage
100~240VAC
Safety Standards
EN61347-1, EN61347-2-13
Output Voltage Options
Single
Working Temperature
-40~+85°C
PDF Datasheet
ECP4-ILP.pdf
